Prosoft

• Technical Specifications
  • Power and Mechanical Parameters
    • It has a maximum current load of 800 mA at 5 VDC power supply. It adopts a standard 1769 single-slot design and is compatible with the 1769 backplane, which can be smoothly installed into the corresponding CompactLogix chassis.
    • It is recognized as a standard input and output module by the CompactLogix system, enabling unobstructed access to processor memory for smooth data transfer between the processor and the module.
  • Communication Parameters
    • It is equipped with a 10/100 Base-T Ethernet-compatible interface. The server driver can support connections to up to five Modbus TCP/IP clients through service port 502 with standard MBAP messaging, and another five clients through Modbus RTU/ASCII on service port 2000.
    • The client driver can actively read and write data with Modbus TCP/IP-compatible devices, and a single client can support up to 100 commands that can be sent to one or multiple servers. All data mapping of the module starts from Modbus register 40001.
  • Compatibility Parameters
    • It is compatible with all CompactLogix and MicroLogix 1500 LRP controllers, but it cannot be used with 1769-QBFC1B, 1769-L16X and 1769-L18X models. It supports Enron, Daniels and other floating-point data types to meet diverse data processing needs.

• Interface: PROFIBUS DP-V1

• Product Name:​ EtherNet/IP to ASCII Communication Gateway
• Product Introduction:​ Standalone DIN-rail industrial protocol gateway that bridges EtherNet/IP-enabled PACs (Rockwell ControlLogix/CompactLogix, Schneider) with serial ASCII devices such as weigh scales, barcode readers, printers, and legacy terminals. Acts as EtherNet/IP Client/Server and ASCII Master/Slave simultaneously.

Core Function

• Protocol Conversion: Bridges EtherNet/IP (CIP, PCCC) and Siemens Industrial Ethernet protocols for seamless interoperability between Rockwell controllers and Siemens PACs .
• Data Exchange: Supports high-speed bidirectional transfers of up to 10,000 16-bit registers, ideal for large-scale industrial data synchronization .

• Power and Physical Parameters
  • It uses a 24VDC power supply and has a power consumption of 1.5W, which is compatible with standard industrial power supply configurations.
  • Its dimensions are 110 mm × 95 mm × 50 mm and weighs 0.5 kg. The compact size allows for flexible installation in industrial control cabinets.
  • It operates within a temperature range of -40°C to 85°C and can withstand a humidity range of 5% to 95% without condensation, adapting to harsh industrial environmental conditions.
• Communication Parameters
  • It serves as a PROFIBUS DPV1 master interface and supports baud rates ranging from 9600 bps to 12 Mbps, with automatic baud rate detection for all valid PROFIBUS DPV1 rates.
  • It can connect up to 125 slave devices when using repeaters, and can also connect PROFIBUS PA slaves to the network through DP/PA couplers or links.
  • It requires Ethernet connectivity for normal operation, and uses UDP messaging to back up data in status registers between modules to determine switchover conditions.
