ProSoft PLX32-MBTCP-SIE

• Wireless Communication Parameters
  • It operates in the 2.4 GHz frequency band ranging from 2400 MHz to 2483.5 MHz and complies with the IEEE 802.11 b wireless standard.
  • The wireless data rate can reach up to 11 Mbps, with an output power of 32 mW (15 dBm) and a maximum open-air transmission distance of 400 meters.
  • It is equipped with two RP-SMA connectors that support antenna diversity, which enhances the stability of wireless signal reception and transmission.
• PROFIBUS DP Related Parameters
  • It is equipped with an RS-485 PROFIBUS DP interface and supports PROFIBUS DP and DP-V1 protocols.
  • The communication baud rate of PROFIBUS DP ranges from 9.6 kbps to 12 Mbps, and it can support up to 125 PROFIBUS DP slave devices.
• Power and Mechanical Parameters
  • It has a power supply requirement of 10 - 36 VDC, adapting to different industrial power supply environments.
  • It adopts a DIN rail mounting design with an IP20 protection rating, which fits the standard installation specifications of industrial control cabinets and prevents dust intrusion effectively.

• Technical Specifications
  • Power and Mechanical Parameters
    • It has a maximum current load of 800 mA at 5 VDC power supply. It adopts a standard 1769 single-slot design and is compatible with the 1769 backplane, which can be smoothly installed into the corresponding CompactLogix chassis.
    • It is recognized as a standard input and output module by the CompactLogix system, enabling unobstructed access to processor memory for smooth data transfer between the processor and the module.
  • Communication Parameters
    • It is equipped with a 10/100 Base-T Ethernet-compatible interface. The server driver can support connections to up to five Modbus TCP/IP clients through service port 502 with standard MBAP messaging, and another five clients through Modbus RTU/ASCII on service port 2000.
    • The client driver can actively read and write data with Modbus TCP/IP-compatible devices, and a single client can support up to 100 commands that can be sent to one or multiple servers. All data mapping of the module starts from Modbus register 40001.
  • Compatibility Parameters
    • It is compatible with all CompactLogix and MicroLogix 1500 LRP controllers, but it cannot be used with 1769-QBFC1B, 1769-L16X and 1769-L18X models. It supports Enron, Daniels and other floating-point data types to meet diverse data processing needs.

Core Function

• Protocol Conversion: Bridges EtherNet/IP (CIP, PCCC) and Siemens Industrial Ethernet protocols for seamless interoperability between Rockwell controllers and Siemens PACs .
• Data Exchange: Supports high-speed bidirectional transfers of up to 10,000 16-bit registers, ideal for large-scale industrial data synchronization .

• Power and Physical Parameters
  • It uses a 24VDC power supply and has a power consumption of 1.5W, which is compatible with standard industrial power supply configurations.
  • Its dimensions are 110 mm × 95 mm × 50 mm and weighs 0.5 kg. The compact size allows for flexible installation in industrial control cabinets.
  • It operates within a temperature range of -40°C to 85°C and can withstand a humidity range of 5% to 95% without condensation, adapting to harsh industrial environmental conditions.
• Communication Parameters
  • It serves as a PROFIBUS DPV1 master interface and supports baud rates ranging from 9600 bps to 12 Mbps, with automatic baud rate detection for all valid PROFIBUS DPV1 rates.
  • It can connect up to 125 slave devices when using repeaters, and can also connect PROFIBUS PA slaves to the network through DP/PA couplers or links.
  • It requires Ethernet connectivity for normal operation, and uses UDP messaging to back up data in status registers between modules to determine switchover conditions.
