Bently Nevada 3500/15-05-05-CN Universal AC Power Supply Module

Technical Specifications – Input range : 90–265 Vac rms, 47–63 Hz; also 120–340 Vdc – Nominal output : 24 Vdc ±1 %, 5 A, 120 W – Hold-up time : >20 ms at 115 Vac / full load – Efficiency : >82 % @ 230 Vac, typical – Power factor : >0.98 (active PFC) – Inrush current : <20 A peak cold start – Ripple & noise : <50 mV pp (20 MHz BW) – Isolation : 1 500 Vac input-to-output, 1 500 Vac input-to-ground – Protection : overload, short-circuit, over-voltage, thermal shutdown with auto-recovery – MTBF : >250 000 h @ 45 °C per MIL-HDBK-217F – Operating temperature : –40 °C to +70 °C full power – Storage temperature : –40 °C to +85 °C – Humidity : 5 %–95 % non-condensing – Shock / vibration : 15 g half-sine 11 ms; 2 g sinusoidal 5–500 Hz operational – Enclosure : IP20 front, UL 94 V-0 polycarbonate, flame-retardant – Dimensions : 120.7 mm × 50.8 mm × 251.5 mm (4.75" × 2.0" × 9.9") – Weight : 1.39 kg (3.06 lb) – Agency approvals : CE, UL/cUL Listed (UL 508), CN Ex Zone 2, RoHS
Read more
Quick view

Bently Nevada 3500/15-05-05-R0 Universal AC Power Supply Module

Technical Specifications – Input range : 85–264 Vac rms, 47–63 Hz; also 120–340 Vdc – Nominal output : 24 Vdc ±1 %, 5 A, 120 W – Hold-up time : >20 ms at 115 Vac / full load – Efficiency : >85 % @ 230 Vac, typical – Power factor : >0.98 (active PFC) – Inrush current : <20 A peak cold start – Ripple & noise : <50 mV pp (20 MHz BW) – Isolation : 1 500 Vac input-to-output, 1 500 Vac input-to-ground – Protection : overload, short-circuit, over-voltage, thermal shutdown with auto-recovery – MTBF : >250 000 h @ 45 °C per MIL-HDBK-217F – Operating temperature : –40 °C to +70 °C full power – Storage temperature : –40 °C to +85 °C – Humidity : 5 %–95 % non-condensing – Shock / vibration : 15 g half-sine 11 ms; 2 g sinusoidal 5–500 Hz operational – Enclosure : IP20 front, UL 94 V-0 polycarbonate, flame-retardant – Dimensions : 120.7 mm × 50.8 mm × 251.5 mm (4.75" × 2.0" × 9.9") – Weight : 1.39 kg (3.06 lb) – Agency approvals : CE, UL/cUL Listed (UL 508), RoHS
Read more
Quick view

Bently Nevada 3500/20 125744-02 Rack Interface Module (RIM)

Technical Specifications – Input channels : 4 digital communication ports (Ethernet + serial) – Sampling / update rate : 1 000 Hz per channel for real-time data streaming – Resolution : 16 bits for configuration and event tagging – On-board storage : 1 GB for event log, waveform buffer and firmware – Communication protocols : Modbus/TCP, proprietary Bently protocol, RS-232/RS-485 @ 38.4 kbaud – Power consumption : 4.75 W typical, powered directly from 3500 rack 24 Vdc back-plane – Isolation : 1 500 Vac channel-to-ground, 500 V channel-to-channel – Cable length : 2.1 m (7 ft) max for serial service lead – MTBF : >250 000 h @ 45 °C per MIL-HDBK-217F – Operating temperature : –20 °C to +70 °C full performance – Storage temperature : –40 °C to +85 °C – Humidity : 5 %–95 % non-condensing – Shock / vibration : 15 g half-sine 11 ms; 2 g 5–500 Hz operational – Dimensions : 75 mm × 95 mm × 25 mm (2.95" × 3.74" × 0.98") – Weight : 0.2 kg (0.44 lb) – Agency approvals : CE, UL/cUL Class I Div 2, ATEX Zone 2, RoHS
Read more
Quick view

Bently Nevada 3500/20 125760-01 Rack Interface Module (RIM) – Data Manager I/O Card

Technical Specifications – Processor & memory : 1 GHz ARM dual-core, 2 GB DDR3 RAM, 1 GB flash for firmware & event buffer – Input channels : 4 independent digital/analog ports, software-configurable for eddy-current, accelerometer, velocity or TTL speed probes – Measurable parameters : vibration velocity, acceleration, displacement, shaft position, phase, speed – Frequency range : 0.5 Hz – 10 kHz (–3 dB) with selectable high-pass, low-pass and 50/60 Hz notch filters – Sampling rate : 24 kHz max per channel, synchronous across all 3500 monitors – Resolution : 16-bit ADC, <0.02 % linearity, <30 ppm/°C drift – Data storage : >1 000 000 measurement points or 1 000 alarm transients with time stamp – Communication ports : – 10/100 Mb copper Ethernet (Modbus TCP, proprietary Bently protocol) – RS-232 / RS-485 (38.4 kbaud, Modbus RTU, DDE) – Optional fiber-optic Ethernet for Zone-2 hazardous areas – Isolation : 1 500 Vac channel-to-ground, 500 V channel-to-channel – Power draw : 5 W typical, supplied directly from 3500 rack 24 Vdc back-plane – MTBF : >250 000 h @ 45 °C per MIL-HDBK-217F – Operating temperature : –40 °C to +85 °C (no fan required) – Storage temperature : –55 °C to +125 °C – Humidity : 5 %–95 % non-condensing – Shock / vibration : 15 g half-sine 11 ms; 5 g 5–500 Hz sinusoidal operational – Dimensions : 120 mm × 75 mm × 25 mm (4.75" × 2.95" × 0.98") – Weight : 0.2 kg (0.44 lb) – Agency approvals : CE, UL/cUL Class I Div 2, ATEX Zone 2, IECEx, RoHS
Read more
Quick view

Bently Nevada 3500/22-01-01-00 Transient Data Interface (TDI) Module

Technical Specifications – Input channels : 8 vibration/speed/process channels, software-configurable – Sampling rate : 8 kHz max per dynamic channel, synchronous across the rack – Resolution : 16-bit ADC, <0.02 % non-linearity – Frequency range : 0.5 Hz – 4 kHz (–3 dB) with programmable high-pass, low-pass and notch filters – On-board memory : 512 MB for transient buffer, event log and firmware – Communication ports : – 10/100 Mb copper Ethernet (Modbus TCP, proprietary Bently protocol) – RS-232 / RS-485 (38.4 kbaud, Modbus RTU) – Power draw : 7.7 W typical, supplied directly from 3500 rack 24 Vdc back-plane – Isolation : 1 500 Vac channel-to-ground, 500 V channel-to-channel – MTBF : >200 000 h @ 45 °C per MIL-HDBK-217F – Operating temperature : –40 °C to +85 °C full performance – Storage temperature : –55 °C to +125 °C – Humidity : 5 %–95 % non-condensing – Shock / vibration : 15 g half-sine 11 ms; 2 g 5–500 Hz operational – Dimensions : 115 mm × 124 mm × 45 mm (4.5" × 4.9" × 1.8") – Weight : 0.45 kg (1 lb) – Agency approvals : CE, UL/cUL Class I Div 2, ATEX/IECEx Zone 2, RoHS
Read more
Quick view

Bently Nevada 3500/22M 138607-01 Transient Data Interface (TDI) Module

Technical Specifications – Data acquisition : 22 dynamic channels, 24 static/process channels – Sampling rate : 102.4 kHz per dynamic channel, synchronous across the rack – Resolution : 16-bit ADC, <0.02 % non-linearity, 30 ppm/°C drift – Frequency range : 0.3 Hz – 40 kHz (–3 dB) with programmable filters – On-board memory : 2 GB for transient buffer, event log and firmware – Communication ports : – 10/100BASE-TX auto-sensing copper Ethernet – 100BASE-FX fiber-optic Ethernet (optional) – USB-B service port (38.4 kbaud) – RS-232/RS-485 (Modbus RTU) – Protocols : Modbus TCP/RTU, proprietary Bently protocol, OPC UA tunnel – Power supply : 24 Vdc from rack back-plane, 10.5 W typical, <15 W max – Isolation : 1 500 Vac channel-to-ground, 500 V channel-to-channel – MTBF : >250 000 h @ 45 °C per MIL-HDBK-217F – Operating temperature : –40 °C to +70 °C full performance – Storage temperature : –55 °C to +125 °C – Humidity : 5 %–95 % non-condensing – Shock / vibration : 15 g half-sine 11 ms; 5 g 5–500 Hz operational – Dimensions : 229 mm × 140 mm × 48 mm (9.0" × 5.5" × 1.9") – Weight : 1.0 kg (2.2 lb) – Agency approvals : CE, UL/cUL Class I Div 2, ATEX/IECEx Zone 2, RoHS, ABS marine
Read more
Quick view

Bently Nevada 3500/22M 138607-01 Transient Data Interface (TDI) Module

Technical Specifications – Input channels : 22 dynamic + 24 static/process channels – Sampling rate : 102.4 kHz per dynamic channel, synchronous across the rack – Resolution : 16-bit ADC, <0.02 % non-linearity, 30 ppm/°C drift – Frequency range : 0.3 Hz – 40 kHz (–3 dB) with programmable filters – On-board memory : 2 GB for transient buffer, event log and firmware – Communication ports : – 10/100BASE-TX copper Ethernet – 100BASE-FX fiber-optic Ethernet (optional) – USB-B service port – RS-232 / RS-485 Modbus RTU – Protocols : Modbus TCP/RTU, proprietary Bently protocol, OPC UA tunnel – Power draw : 24 Vdc from rack back-plane, 10.5 W typical, <15 W max – Isolation : 1 500 Vac channel-to-ground, 500 V channel-to-channel – MTBF : >250 000 h @ 45 °C per MIL-HDBK-217F – Operating temperature : –40 °C to +85 °C full performance – Storage temperature : –55 °C to +125 °C – Humidity : 5 %–95 % non-condensing – Shock / vibration : 15 g half-sine 11 ms; 5 g 5–500 Hz operational – Dimensions : 229 mm × 140 mm × 48 mm (9.0" × 5.5" × 1.9") – Weight : 1.0 kg (2.2 lb) – Agency approvals : CE, UL/cUL Class I Div 2, ATEX/IECEx Zone 2, RoHS, ABS marine
Read more
Quick view

Bently Nevada 3500/22M 138607-01 Transient Data Interface (TDI) Module

Technical Specifications – Host position : slot 1 (full-height), mandatory in every 3500 rack – Input channels : 22 dynamic + 24 static/process channels – Sampling rate : 102.4 kHz per dynamic channel, synchronous across the rack – Resolution : 16-bit ADC, <0.02 % non-linearity, 30 ppm/°C drift – Frequency range : 0.3 Hz – 40 kHz (–3 dB) with programmable high-pass, low-pass and notch filters – On-board memory : 2 GB for transient buffer, event log and firmware – Communication ports : – 10/100BASE-TX auto-negotiating copper Ethernet (RJ-45) – 100BASE-FX fiber-optic Ethernet (optional) – USB-B front service port (38.4 kbaud) – RS-232 / RS-485 (38.4 kbaud, Modbus RTU) – Protocols : Modbus TCP/RTU, proprietary Bently protocol, OPC UA tunnel – Power draw : 24 Vdc from rack back-plane, 10.5 W typical, <15 W max – Isolation : 1 500 Vac channel-to-ground, 500 V channel-to-channel – MTBF : >250 000 h @ 45 °C per MIL-HDBK-217F – Operating temperature : –40 °C to +70 °C full performance – Storage temperature : –40 °C to +85 °C – Humidity : 5 %–95 % non-condensing – Shock / vibration : 15 g half-sine 11 ms; 5 g 5–500 Hz operational – Dimensions : 229 mm × 140 mm × 48 mm (9.0" × 5.5" × 1.9") – Weight : 1.0 kg (2.2 lb) – Agency approvals : CE, UL/cUL Class I Div 2, ATEX/IECEx Zone 2, RoHS, ABS marine
Read more
Quick view

Bently Nevada 3500/22M 146031-01 Transient Data Interface I/O Module

Technical Specifications – Host module : 3500/22M Transient Data Interface (slot-1, full-height) – I/O channels : 22 dynamic + 24 static/process channels via TDI back-plane – Sampling rate : 25.6 kHz / 51.2 kHz / 102.4 kHz selectable per dynamic channel – Resolution : 16-bit ADC, <0.02 % non-linearity, 30 ppm/°C drift – Frequency range : 0.3 Hz – 40 kHz (–3 dB) with programmable filters – On-board memory : 2 GB for transient buffer, event log and firmware – Communication ports : – 2 × 10/100BASE-TX copper Ethernet (RJ-45) – 1 × RS-232 / RS-485 (38.4 kbaud, Modbus RTU) – Protocols : Modbus TCP/RTU, proprietary Bently protocol, OPC UA tunnel – Power supply : 24 Vdc from rack back-plane, 10.5 W typical, <15 W max – Isolation : 1 500 Vac channel-to-ground, 500 V channel-to-channel – MTBF : >250 000 h @ 45 °C per MIL-HDBK-217F – Operating temperature : –40 °C to +85 °C full performance – Storage temperature : –55 °C to +125 °C – Humidity : 5 %–95 % non-condensing – Shock / vibration : 15 g half-sine 11 ms; 5 g 5–500 Hz operational – Dimensions : 101.6 mm × 76.2 mm × 25.4 mm (4" × 3" × 1") – Weight : 0.2 kg (0.44 lb) – Enclosure / PCB : conformal-coated, IP65 bulkhead seal on RJ-45 ports – Agency approvals : CE, UL/cUL Class I Div 2, ATEX/IECEx Zone 2, RoHS
Read more
Quick view

Bently Nevada 3500/22M 288055-01 – Transient Data Interface Module (TDI)

Technical Specifications:

  • Type: Proximity Transducer Driver Module
  • Compatibility: Designed to fit into the Bently Nevada 3500 series rack system.
  • Channels: Typically supports multiple channels (e.g., up to 6 channels) depending on the configuration, allowing for monitoring of several machine positions simultaneously.
  • Input Voltage: Operates within specified voltage ranges suitable for industrial environments.
  • Environmental Tolerance: Engineered to withstand harsh industrial conditions including temperature extremes, humidity, and electromagnetic interference.
  • Certifications: Meets industry standards for safety and reliability, ensuring suitability for use in critical applications.
Read more
Quick view

Bently Nevada 3500/22M 288055-01 Transient Data Interface (TDI) Module

Technical Specifications – Input channels : 22 dynamic + 24 static/process channels – Sampling rate : 250 kHz max per dynamic channel, synchronous across the rack – Resolution : 16-bit ADC, <0.02 % non-linearity, 30 ppm/°C drift – Frequency range : 0.3 Hz – 100 kHz (–3 dB) with programmable high-pass, low-pass and notch filters – On-board memory : 2 GB for transient buffer, event log and firmware – Communication ports : – 10/100BASE-TX auto-negotiating copper Ethernet (RJ-45) – 100BASE-FX fiber-optic Ethernet (optional) – USB-B front service port (38.4 kbaud) – RS-232 / RS-485 (38.4 kbaud, Modbus RTU) – Protocols : Modbus TCP/RTU, proprietary Bently protocol, OPC UA tunnel – Power supply : 24 Vdc from rack back-plane, 10.5 W typical, <25 W max – Isolation : 1 500 Vac channel-to-ground, 500 V channel-to-channel – MTBF : >250 000 h @ 45 °C per MIL-HDBK-217F – Operating temperature : –40 °C to +85 °C full performance – Storage temperature : –55 °C to +125 °C – Humidity : 0 %–95 % non-condensing – Shock / vibration : 15 g half-sine 11 ms; 5 g 5–500 Hz operational – Dimensions : 241 mm × 58 mm × 28 mm (9.5" × 2.3" × 1.1") – Weight : 0.91 kg (2.0 lb) for TDI module; 0.2 kg for I/O card – Enclosure / PCB : conformal-coated, IP65 gasket on Ethernet ports – Agency approvals : CE, UL/cUL Class I Div 2, ATEX/IECEx Zone 2, RoHS, ABS marine
Read more
Quick view

Bently Nevada 3500/22M-01-01-01 Transient Data Interface (TDI) Module

Technical Specifications – Host position : slot 1 (full-height), mandatory in every 3500 rack – Input channels : 22 dynamic + 24 static/process channels – Sampling rate : 25.6 kHz / 51.2 kHz / 102.4 kHz selectable per dynamic channel – Resolution : 16-bit ADC, <0.02 % non-linearity, 30 ppm/°C drift – Frequency range : 0.3 Hz – 40 kHz (–3 dB) with programmable high-pass, low-pass and notch filters – On-board memory : 2 GB for transient buffer, event log and firmware – Communication ports : – 10/100BASE-TX auto-negotiating copper Ethernet (RJ-45) – 100BASE-FX fiber-optic Ethernet (optional) – USB-B front service port (38.4 kbaud) – RS-232 / RS-485 (38.4 kbaud, Modbus RTU) – Protocols : Modbus TCP/RTU, proprietary Bently protocol, OPC UA tunnel – Power draw : 24 Vdc from rack back-plane, 10.5 W typical, <15 W max – Isolation : 1 500 Vac channel-to-ground, 500 V channel-to-channel – MTBF : >250 000 h @ 45 °C per MIL-HDBK-217F – Operating temperature : –40 °C to +85 °C full performance – Storage temperature : –55 °C to +125 °C – Humidity : 5 %–95 % non-condensing – Shock / vibration : 15 g half-sine 11 ms; 5 g 5–500 Hz operational – Dimensions : 241 mm × 58 mm × 28 mm (9.5" × 2.3" × 1.1") – Weight : 0.91 kg (2.0 lb) for TDI module; 0.2 kg for I/O card – Agency approvals : CE, UL/cUL Class I Div 2, ATEX/IECEx Zone 2, RoHS, ABS marine
Read more
Quick view
