The IC694ALG392 is a high‑precision 8‑channel analog current/voltage output module from GE Fanuc (Emerson Automation) for PACSystems RX3i PLCs, offering 8 single‑ended channels configurable per channel to 0–10V, -10–+10V (voltage) or 0–20mA, 4–20mA (current) ranges. It delivers 16‑bit resolution, ±0.25% full‑scale accuracy at 25°C, and 8ms update for all 8 channels, with 1500VAC input‑to‑backplane isolation, open‑wire detection in current mode, and LED diagnostics (Module OK, Power, Channel Faults). The module fits any RX3i I/O slot, requiring +5VDC backplane power (110mA) and 20–30VDC external power (315mA), converting digital data into precise analog signals to control industrial actuators in real‑time process applications.

The IC694MDL753 is a 32‑channel positive logic (sourcing) digital output module from GE Fanuc (Emerson Automation) for PACSystems RX3i PLCs, delivering 32 discrete outputs organized into 4 isolated groups of 8 channels, each with its own common terminal. It operates at 12–24 VDC (10.2–28.8 VDC range), sources 0.5A per point (4A max per group, 3A per common pin), and features 250VAC continuous field‑to‑backplane isolation (1500VAC surge for 1 minute) and 50VAC group‑to‑group isolation (500VAC surge). The module uses opto‑couplers for isolation, has LED diagnostics (Module OK, Power, Group/Channel Faults), and forces all outputs OFF during CPU/backplane power loss (external power active). It fits any RX3i I/O slot, requiring +5VDC backplane power (260mA max) and user‑supplied 12–24 VDC external power, converting digital commands into switching signals for industrial loads.

The IC694MDL940 is a 16‑channel normally‑open (Form A) relay output module from GE Fanuc (Emerson Automation) for PACSystems RX3i PLCs, offering 16 individually isolated outputs split into 4 groups of 4, each with a dedicated common terminal. It switches AC/DC loads (5–250VAC, 5–30VDC) with 2A per point (pilot duty), 4A per group common, and 5A inrush handling, plus 250VAC continuous (1500VAC surge) field‑to‑backplane/point‑to‑point isolation. It has 15ms on/off response, per‑channel LED indicators, and runs on +24VDC backplane power (135mA) with no external supply needed. The single‑slot module converts PLC digital commands into relay‑switched signals for industrial actuators, ideal for mixed AC/DC control with noise immunity and safety isolation.

The IC695ACC412 is a capacitor-based energy pack accessory for the GE Fanuc PACSystems RX3i IC695CPE330 controller, preserving user memory during power loss via an internal capacitor array. It mounts at the energy pack bottom, provides 60 seconds of typical memory retention, charges fully in 60–90 minutes, and uses IN/OUT/STAT LEDs for status/charging. The module carries T4A temperature code, suits Class I, Division 2, Groups A–D hazardous locations, and meets UL/CE safety standards, ensuring data integrity for mission-critical industrial control systems.

The IC695ALG600 is an 8-channel universal analog input module for PACSystems RX3i, split into 2 isolated groups of 4 channels, plus 2 dedicated Cold Junction Compensation (CJC) channels for thermocouple accuracy. It is fully software-configurable via Proficy Machine Edition (no jumpers), supporting individual channel setup for voltage, current, thermocouple, RTD, and resistance inputs. It offers 6 selectable hardware filter frequencies (8–1000 Hz), 11–16 - bit resolution (per configuration), and full autocalibration. The module provides 250 VAC continuous optical isolation (field to backplane) and group - to - group isolation, with on - board diagnostics including open - circuit (most types) and RTD short - circuit detection. It uses a detachable terminal board (IC695TBB016/IC695TBS016), supports hot - swap, and operates with RX3i CPUs (release 9.00+), delivering flexible, high - precision analog signal acquisition for industrial automation.
