TRICONEX 2401 Digital Output Module
Technical Specifications
- Output Channels: Multiple digital output channels for controlling various external devices.
- Redundancy Support: Compatible with other TRICONEX modules to support Triple Modular Redundancy (TMR) design, ensuring system operation even with single-point failures.
- Power Supply: Typically operates on 24V DC power input.
- Operating Temperature Range: Generally from -40°C to +70°C, suitable for extreme industrial environments.
- Storage Temperature Range: From -40°C to +85°C for long-term storage reliability.
- Communication Protocols: Supports various communication protocols for seamless integration with other devices and systems.
- Hot-Swappable: Allows for easy maintenance and replacement without interrupting system operation.
TRICONEX 2301 Controller Module
Technical Specifications
- Redundancy Architecture: Triple Modular Redundancy (TMR) structure for fault tolerance and high availability.
- Real-Time Control: Supports high-speed, real-time data processing to ensure rapid system response.
- Safety Compliance: Meets SIL3 (Safety Integrity Level 3) standards, making it suitable for critical safety applications.
- Modular Design: Hot-swappable for easy maintenance and expansion without interrupting system operation.
- Communication Protocols: Supports Modbus, Ethernet, and other protocols for seamless integration with other devices and systems.
- Operating Temperature Range: Typically from -40°C to +70°C, ensuring operation in extreme environments.
- Storage Temperature Range: From -40°C to +85°C for long-term storage reliability.
- Power Supply: 24V DC input for stable power operation.
TRICONEX 2281 Safety Controller Modul
Technical Specifications
- Redundancy Architecture: Triple Modular Redundancy (TMR) for fault tolerance and high availability.
- Input Voltage: 24V DC
- Power Consumption: Approximately 20W
- Installation Method: Standard DIN rail mounting
- Operating Temperature Range: 0°C to +60°C
- Storage Temperature Range: -40°C to +85°C
- Protection Class: IP20
- Supported Programming Software: TriStation 1131
- Compatible System: TRICON SIS Control System
- Certification Standards: IEC 61508 SIL 3, FM, ATEX
TRICONEX 2101 Industrial Controller
Technical Specifications
- Input Power: 24V DC
- Number of Channels: 16
- Interface Types: RS-232, RS-485, Modbus
- Operating Temperature Range: -40°C to 70°C
- Storage Temperature Range: -40°C to 85°C
- Product Dimensions: 19-inch 2U rack-mountable design for easy installation in control cabinets
- Redundancy Architecture: TMR (Triple Modular Redundant) for fault tolerance and high availability
TRICONEX MA2211-100 Digital Input Module
Technical Specifications
- Input Channels: The MA2211-100 typically features multiple digital input channels, allowing it to monitor the status of various digital signal sources simultaneously.
- Signal Types: It supports digital signals, including switch signals, button signals, and sensor signals. Some sources also suggest it may have capabilities for handling analog signals in certain configurations.
- Communication Interface: The module is equipped with a communication interface, such as PCIe, enabling seamless integration with other control systems, PLCs (Programmable Logic Controllers), or DCSs (Distributed Control Systems).
- Electrical Isolation: It provides electrical isolation to prevent external electrical interference from affecting the system, enhancing overall reliability.
- Measurement Functions: In addition to basic digital input capabilities, the MA2211-100 may offer measurement functions for specific physical quantities like temperature, pressure, flow, humidity, and liquid level, with high precision and reliability.
- Physical Characteristics: The module is typically designed to be durable and suitable for industrial environments, with a robust casing and resistance to harsh conditions.
TRICONEX 8301A Communication Module
Technical Specifications
- Model: 8301A
- Manufacturer: TRICONEX (a brand of Schneider Electric)
- Function: Communication module for connecting I/O modules to the TRICONEX controller
- Input/Output Types: Supports digital input and output signals
- Redundancy: Part of the TRICONEX TMR (Triple Modular Redundant) architecture, ensuring fault tolerance and high availability
- Voltage Range: Typically operates within a standard industrial voltage range, compatible with 24VDC systems
- Environmental Conditions: Designed to withstand harsh industrial environments, including extreme temperatures and vibrations
- Mounting: Rack-mounted for easy integration into existing control systems
- Diagnostic Capabilities: Includes built-in diagnostic features for monitoring module status and troubleshooting issues
TRICONEX V2-V3 5101S2 TMR Safety Main Controller
Technical Specifications
- Product Model: V2-V3 5101S2
- Manufacturer: TRICONEX (Schneider Electric)
- Redundancy Architecture: TMR (Triple Modular Redundant)
- Safety Integrity Level: SIL 3 certified by TÜV Rheinland, suitable for all safety and critical control applications.
- Input/Output Capacity: Scalable from 16 TMR I/O channels to over 730,000 TMR I/O channels.
- Voltage Range: Typically operates within a voltage range of 16-30 VDC, with a maximum voltage of 36 VDC.
- Power Consumption: Less than 10 watts per power module.
- Isolation: Point isolation of 1500 VDC for enhanced safety.
- Diagnostic Indicators: Provides diagnostic indicators for each point's on/off status, module status (pass, fault, active), and field alarms.
TRICONEX 9566-810 Digital Input Terminal Panel
Technical Specifications
- Input Points: The 9566-810 typically supports 32 digital input points, allowing for the connection of multiple field devices.
- Input Type: It is designed for digital input signals, which can be either dry contacts (relay contacts) or wet contacts (voltage signals).
- Voltage Range: The panel operates within a specified voltage range, typically compatible with 24VDC systems, ensuring reliable signal transmission.
- Connection Method: It features screw-type terminal blocks for easy and secure connection of field wiring.
- Environmental Conditions: The 9566-810 is built to withstand harsh industrial environments, with a wide operating temperature range and robust construction.
- Mounting: It is designed for rack-mounted installation, facilitating easy integration into existing control systems.
- Protection: The panel includes protection mechanisms such as fuses to safeguard against overcurrent conditions.
