Vibro-Meter VMF-MPC4 200-510-111-034/200-510-070-113

Product Overview
The MPC4 (Machine Protection Card 4-channel) is the computational core of the VM600 MPS. It digitizes dynamic signals from the IOC4T, performs real-time DSP filtering, integration/differentiation, order tracking, and compares results against programmable Alert and Danger thresholds. Supports SIL versions (SIL 1/2) for functional safety applications. Interfaces to RLC16 for relay expansion and to CPUM for networking.
Category:
Description
Technical Specifications
  • Inputs Handled:​ 4 dynamic + 2 tacho (via paired IOC4T)
  • Signal Processing:​ Digital filtering (broadband/narrowband), integration (accel→vel→disp), differentiation, RMS/peak/pk-pk, 1× / 2× vector, order tracking
  • FFT Analysis:​ Up to 8192-point, 6400 lines spectrum
  • Alarm Functions:​ Alert & Danger with programmable delay, hysteresis, hold; adaptive to speed (trip multiplier during run-up/coast-down)
  • Logic:​ Supports voting logic (1oo2, 2oo3 etc.) when multiple MPC4s are present
  • Self-Diagnostics:​ Sensor OK (open/short), probe gap voltage monitoring, module health
  • Front Panel:​ BNC monitor points, 7 status LEDs (Power, Comms, Ch1–Ch4 Alarm)
  • Interface:​ RS-232 (config port), VM600 backplane bus; Ethernet via CPUM
  • Hot-Swap:​ Yes (with rack power stable)
  • Operating Temp.:​ –25 °C to +65 °C
  • Certification:​ API 670, IEC 61508SIL 1 (SIL version available)
Application Areas
Steam/gas turbines, centrifugal compressors, large motors, pumps, and fans in power, oil & gas, and heavy industry.
