KOLLMORGEN CP310250

Technical Specifications

• Input Power Specification: Single/3-phase 230 VAC ±10%, 50/60 Hz mains supply
• Continuous Output Capacity: 4.6 kVA
• Continuous RMS Output Current: 12 A
• Peak Overload RMS Output Current: 30 A, maximum sustained overload duration 30 s
• Supported Encoder Feedback Protocols: EnDat 2.1/2.2, HiRes, Sine/Cosine 1 Vpp, A/B/Z incremental encoder
• Built-in Communication Ports: SERCOS III real-time motion bus, RS485 Modbus RTU, Ethernet/IP industrial Ethernet
• Native Control Modes: Position closed loop, speed closed loop, torque closed loop
• Internal Brake Circuit: Integrated dynamic braking resistor circuit, external braking resistor terminal block reserved
• Digital I/O Points: 16 configurable digital input channels, 8 configurable digital output channels
• Physical Outer Dimensions: 110 mm (W) × 260 mm (H) × 165 mm (D)
• Net Mass: 3.7 kg
• Enclosure Protection Grade: IP00 (cabinet interior installation only)
• Continuous Operating Temperature: 0 ℃ ~ +45 ℃ without condensation
• Storage Temperature Band: -20 ℃ ~ +70 ℃
• Operating Humidity Range: 5% ~ 90% RH, dew formation prohibited
• Vibration Resistance Standard: IEC 60068-2-6, 10–150 Hz, 0.7 g acceleration

Function Features

1. Three independent full closed-loop control algorithms switchable in real time without power cycle
2. Built-in automatic encoder signal calibration circuit eliminating manual feedback offset tuning
3. Dynamic braking circuit for rapid motor deceleration under emergency stop and high inertia load conditions
4. Full hardware fault diagnosis covering overcurrent, overvoltage, undervoltage, overtemperature, encoder loss, short-circuit protection
5. SERCOS III 100 Mbps real-time motion bus for multi-axis synchronous coordinated motion
6. Configurable electronic gearing, electronic cam and flying shear motion function blocks native to firmware
7. Multi-channel digital I/O logic for direct connection of limit switches, home sensors and safety interlock relays
8. Firmware upgradable via Ethernet/IP port without hardware disassembly

Performance Parameters

• Peak motor torque output capacity: 250% rated continuous torque
• Position loop bandwidth maximum: 1200 Hz
• Speed loop bandwidth maximum: 800 Hz
• Position positioning repeatability: ±1 encoder pulse
• SERCOS bus synchronization jitter: ≤0.5 μs
• Factory certified MTBF: 92,000 hours under rated operating ambient

Material Composition

• Outer metal housing: Cold rolled steel sheet with matte black electrostatic anti-rust paint coating
• Main power circuit substrate: High-temperature FR-4 heavy copper PCB board
• Power module heat dissipation assembly: Aluminum extruded fin passive radiator
• Signal terminal blocks: Nickel-plated copper alloy, flame retardant PA66 plastic base
• Internal circuit conformal coating: Acrylic insulation coating resisting dust and mild moisture

Structural Characteristics

• Vertical DIN rail cabinet mounting form factor, rear mounting lugs for bolted auxiliary fixation
• Front panel centralized LED status indicator array: POWER, RUN, FAULT, SERCOS, COMM
• Upper terminal block area for high-voltage mains input, motor power and braking resistor wiring
• Lower terminal section dedicated to low-voltage encoder feedback, digital I/O and communication wiring
• Separate wiring partitioning between high-power power circuits and low-voltage signal circuits inside housing

Working Principle

Advantage Highlights

1. 250% peak overload torque capability adapts to high acceleration, high inertia mechanical loads
2. Multi-protocol universal encoder interface compatible with all mainstream KOLLMORGEN servo motor feedback systems
3. Integrated dynamic braking circuit removes mandatory external braking unit for medium inertia equipment
4. SERCOS III high-speed motion bus achieves ultra-low jitter multi-axis synchronous motion control
5. Heavy copper power PCB design reduces internal power loss and heat generation during continuous heavy load operation
6. Onboard electronic cam and flying shear firmware blocks reduce upper controller calculation burden
7. Full set of hardware protection circuits prevents permanent component damage under abnormal mains or mechanical fault conditions

Applicable Industries

Installation Requirements

1. Vertically mount on standard 35 mm DIN rail inside sealed metal industrial control cabinet
2. Maintain minimum 50 mm vertical clearance above and below unit for radiator natural convection cooling
3. Isolate high-voltage power wiring and low-voltage encoder/communication wiring using separate cable ducts
4. Cabinet protective grounding terminal connected with copper wire cross-section ≥2.5 mm², grounding resistance ≤4 Ω
5. Install external forced cooling fan if cabinet internal ambient temperature exceeds 40 ℃
6. Do not mount adjacent to high-power frequency converters or arc-generating contactors

Usage Precautions

1. Cut three-phase mains power supply before connecting or disconnecting motor, encoder and I/O wiring terminals
2. Match external braking resistor resistance and power rating strictly per official datasheet specifications
3. Prevent metal conductive dust accumulation on aluminum radiator fins to avoid heat dissipation failure
4. Do not operate the drive in environments containing acid vapor, oil mist or corrosive industrial gas
5. Execute encoder signal calibration every 12 months for long-term precision positioning stability
6. Unauthorized disassembly of internal power modules voids all factory warranty coverage
