HIMA F7133

Product Name: Quad Power Distribution / Fused Output Module
Product Introduction: Provides 4 monitored and fused 24 V DC output distribution channels for safety actuators, with real-time feedback to CPU and local LED indication.
Technical Specifications:
- Output Channels: 4 monitored circuits

Category: HIMA

Description

- Operating Voltage: 24 V DC (18–30 V)
- Output Current: Typically 0.5 A to 2 A per channel (load-dependent)
- Safety Grade: SIL 3 (IEC 61508)
- Weight: Approx. 0.45–0.60 kg
- Mounting: HIMA 19-inch rack plug-in
Functional Features: Channel-level fault feedback (open/short/overload); front LEDs (green normal, red fault); supports hot-swap replacement; electronic fusing or coordinated with external fuses.
Performance Parameters: Feedback reaction time within scan cycle; diagnostics cover >99% of wire-break and short conditions.
Material Composition: Robust industrial-grade PCB; flame-retardant enclosure; screw terminals with strain relief.
Structural Features: Rack insertion module; clearly labeled terminal rows; status LEDs per channel; 4 SU typical width.
Working Principle: Each 24 V DC output passes through current sense resistor; sense voltage compared to limits; fault latched and reported via backplane; healthy state re-established after fault cleared and acknowledged.
Advantage Highlights: Centralized fused distribution reduces cabinet wiring; immediate visibility of field power issues; SIL 3 rated distribution path.
Applicable Industries: ESD Valve Actuation, Fire & Gas Solenoids, Safety Alarm Annunciation, Process Safety Loops.
Model Series: HIMA F71 Series Power Distribution.
Installation Requirements: Mount in HIMA standard rack; use 24 V DC supply capable of total summed load + margin; torque terminals to spec; label each fused circuit per loop diagram.
Usage Precautions: Do not mix loads exceeding per-channel 2 A rating; reset fault only after confirming field wiring repaired; ensure external short-circuit protection coordination with module’s internal limits; replace only with identical F7133 rated module to maintain SIL certification.
