Product Name:​ HIMA HIMatrix F60 MI 24 01 — Fail-Safe Analog Input Module with Intrinsic Safety (Order No. 982400006 / F60MI24014)
Product Brief:​ A certified safety-related analog input module for the HIMatrix F60 compact safety PLC system. Designed to acquire 4–20 mA or 0–10 V signals from field transmitters located in hazardous areas (Ex i) and convert them with high precision for use in SIL 3 safety logic. Fully TÜV-certified to IEC 61508SIL 3 / IEC 61511SIL 3.
Category:
Description
Technical Specifications:
  • Module Type:​ F60 MI 24 01 (8 or 16-channel analog input depending on firmware/config; commonly 8 AI)
  • Input Signal Types:​ 4–20 mA (active/passive), 0–10 V, ±10 V — software-selectable per channel
  • Resolution:​ 16-bit A/D
  • Accuracy:​ ±0.1 % of full scale (typical)
  • Intrinsic Safety:​ Supports connection to Ex i (ia/ib) field transmitters via certified barrier or integrated IS interface (per HIMA Ex concept)
  • Update Time:​ < 10 ms (typical cycle)
  • Communication:​ Connected via HIMatrix backplane to F60 CPU; SafeEthernet for peer communication
  • Diagnostics:​ Wire break, short-circuit, over-range, under-range detection per channel; module self-test
  • Supply Voltage:​ 24 VDC via backplane
  • Operating Temp:​ –20 to +65 °C (recommended <60 °C for long-term stability)
  • Mounting:​ 35 mm DIN rail, hot-pluggable (with system permission)
  • Certification:​ SIL 3 per IEC 61508; TÜV, CE, cULus, ATEX/IECEx (when used with appropriate IS barriers)
Features:
  • Sensor health monitoring (SHM) — detects transmitter failure vs. true process deviation
  • Configurable limit values for pre-alarm / alarm in safety program
  • Seamless integration with ELOP / SILworX engineering software
Application:​ SIS (Safety Instrumented System) in oil & gas, refining, chemical — e.g., reading pressure transmitter on high-pressure separator for high-high pressure trip; reading temperature for reactor overtemperature protection.
Installation Notes:
  • Insert into designated slot of HIMatrix F60 base unit; tighten retaining screw.
  • Use properly certified IS barriers (e.g. MTL, Pepperl+Fuchs) between Ex i field transmitter and module if module itself is not Ex i certified directly — follow HIMA wiring recommendations.
  • In SILworX, assign channel types and configure diagnostics before downloading to CPU.
