MTL 8206-TI-IS

Product Brief Introduction

This module belongs to Eaton MTL PAC8000 distributed I/O product family, original factory intrinsically safe temperature acquisition card designed for hazardous explosive industrial area. The unit collects resistance signal from field 2/3/4-wire RTD thermal resistance sensors installed in Zone 0/1/2 hazardous locations, converts variable resistance value into standardized digital temperature data via internal high-precision ADC circuit, transmits processed digital data to PAC8000 backplane bus and upper DCS/PLC control system.
Read more
Quick view

MTL 8220-DI-IS

Product Name: 8220-DI-IS 16-Channel Intrinsically Safe Discrete Input Module (MTL 8000 Series I/O)
Product Description: High-density intrinsically safe digital input module designed for signal acquisition from field devices located in hazardous areas. Interfaces with dry contacts, simple apparatus, and NAMUR-compliant proximity detectors, providing galvanically isolated signal transfer from Zone 0/Class I Division 1 hazardous areas to safe-area control systems.
Read more
Quick view

MTL 831C Analog Input Multiplexer

  • Technical Specifications
    • Input and Output Performance
      • It has 16 analog input channels and supports mixed connections of multiple types of sensor signals without the need for additional adapter components.
      • The output signals include 4 - 20mA and 0 - 10V, and the transmission accuracy reaches ±0.1% of span, which guarantees the precision of signal transmission in industrial control processes.
    • Transmission Parameters
      • It relies on a single shielded twisted pair as the data highway for signal and power transmission, with a maximum transmission distance of up to 2 kilometers when used with the MTL838C receiver.
      • It achieves 3-way galvanic isolation among input, output and power circuits, effectively preventing signal interference and ensuring signal integrity.
    • Power Supply
      • The power supply range is 20V DC to 35V DC, and some versions can also adapt to an 8V DC to 32V DC input range, which is compatible with various industrial power supply systems.
    • Physical and Environmental Indicators
      • Its overall dimensions are 10.2 cm × 8 cm × 5 cm and the net weight is 0.12 kg. It supports DIN rail mounting and can also be installed in on-site junction boxes or explosion-proof enclosures.
      • The operating temperature range is -40°C to 70°C, and the storage temperature ranges from -40°C to 85°C. It can work normally in an environment with 5% to 95% relative humidity without condensation, and the protection level reaches IP65.
Read more
Quick view

MTL 8507-BI-DP Profibus-DP Bus Interface Module

Technical Specifications
  • Communication Parameters
    • It complies with the Profibus - DP protocol based on the EN - 50170 standard and adopts the RS - 485 transmission standard.
    • It supports multiple transmission rates including 9.6 kbaud, 19.2 kbaud, 93.75 kbaud, 187.5 kbaud, 500 kbaud, 1.5 mbaud, 6 mbaud and 12 mbaud.
    • The maximum length of the bus segment varies with the transmission rate, and it can reach 1200 meters when the rate is 9.6 kbaud or 19.2 kbaud, and 100 meters when the rate is 6 mbaud or 12 mbaud.
  • Data Capacity
    • The maximum input data including a 2 - byte status word is 240 bytes, and the maximum output data including a 2 - byte control word is 240 bytes, with the total maximum data of input and output reaching 480 bytes.
    • It provides four options for diagnostic telegram lengths, which are 110 bytes, 61 bytes, 13 bytes and 29 bytes, among which 13 bytes is the default length.
Read more
Quick view

MTL 8602‑FT‑ST

Product Introduction MTL intrinsically‑safe optical‑electrical conversion module for signal transmission via fiber optic cables in hazardous areas. It converts electrical signal into optical signal to achieve galvanic isolation and eliminate ground‑loop interference for explosion‑proof industrial zones.
Read more
Quick view

MTL 8610‑FT‑NA

Product Introduction MTL explosion‑proof fiber communication conversion module, used for galvanically isolated bus signal transmission over fiber. It isolates electrical circuits between hazardous field and control room, suppresses surge and ground‑potential difference interference.
Read more
Quick view

MTL 8715-CA-BI Profibus-DP Bus Interface Module Carrier

Technical Specifications
  • Communication Performance
    • It is fully compatible with the Profibus - DP communication protocol, which lays a foundation for seamless connection with Profibus - DP master stations.
    • The maximum LAN transmission speed reaches 6 Mbaud, ensuring efficient and real - time data exchange between the master station and I/O modules.
    • It can support up to 24 I/O modules, which provides sufficient expansion space for the construction of large - scale industrial control systems.
  • Power and Isolation
    • It adopts a 24V DC power supply, and the current rating is 0.25A, which meets the power demand of stable operation of connected modules.
    • The isolation voltage between the safe side and the dangerous side reaches 250V AC, and some versions can reach 2kV, which can effectively block the mutual interference of fault signals between circuits.
  • Environmental Limits
    • The operating temperature range is from -40°C to 85°C, and the storage temperature can withstand the range of -40°C to 80°C, adapting to extreme temperature changes in industrial sites.
    • It can operate normally in an environment with a relative humidity of 5% to 95%, and has an IP20 protection rating, which is suitable for installation and use in control cabinets.
Read more
Quick view

MTL 8810‑HI‑TX

Product Name MTL Intrinsically‑Safe Barrier Product Introduction MTL analog‑output intrinsic safety barrier installed in safe area. It limits voltage and energy delivered to explosion‑proof hazardous zones, prevents spark ignition risk and protects field explosion‑proof instruments.
Read more
Quick view

MTL 8851‑LC‑MT

Product Name MTL Loop Intrinsically‑Safe Barrier Product Introduction Dual‑channel intrinsic safety barrier for signal isolation and energy limitation under explosion‑risk environment. It receives signals from field explosion‑proof transmitters and forwards data to DCS system, protecting instrument loops in hazardous zones.
Read more
Quick view

MTL 8920-PS-DC

Product Name: 8920-PS-DC Intrinsically Safe DC Power Supply Module (MTL 8000 Series)
Product Description: Galvanically isolated DC power supply module designed to provide regulated power to intrinsically safe field circuits in hazardous locations. Converts safe-area 24 VDC input to isolated 12 VDC output for powering IS field devices, with comprehensive overcurrent, overvoltage, and short-circuit protection.
Read more
Quick view

MTL 8920‑PS‑D

Product Name MTL Safety‑Barrier System Power Supply Module Product Introduction Controlled power supply unit for safety‑barrier assemblies. DIN‑rail mounted inside control cabinet, it supplies isolated DC power for a bank of intrinsic safety barriers with built‑in fault protection functions.
Read more
Quick view

MTL 8922-RB-IS

Product Name

  • Full Official Product Name: MTL 8922-RB-IS Dual-Channel Relay Output Intrinsically Safe Isolation Barrier Module
  • Fixed Unique Part Number: 8922-RB-IS
  • Registered Manufacturer: MTL Instruments, an Eaton Group Process Safety Brand, United Kingdom Original Manufacture
  • Product Classification: DIN35 Rail Mounted Galvanically Isolated IS Relay Driver Module for Discrete Digital Signal Between Safe Control Room and Explosive Hazardous Field Area
Read more
