ProSoft MVI56E-PDPMV1

• Technical Specifications
  • Electrical Parameters
    • The power supply voltage ranges from 18VDC to 32VDC, with a maximum current load of 500mA at 32VDC.
    • It adopts a passive power design that draws power directly from the connected Remote I/O scanner, eliminating the need for an independent external power supply and simplifying the wiring layout.
  • Communication Parameters
    • It supports Remote I/O, Modbus RTU and Modbus TCP protocols. The Modbus serial ports support baud rates ranging from 110 baud to 115k baud, with configurable stop bits of 1 or 2, data sizes of 7 or 8 bits, and parity options including none, even and odd.
    • The Remote I/O interface supports baud rates of 57.6k, 115k and 230k, and can realize block data transmission with the scanner, supporting BTR commands up to 63 words and BTW commands up to 64 words.
  • Environmental and Physical Parameters
    • The operating temperature ranges from -40°C to 85°C, and the storage temperature ranges from -40°C to 85°C. It can adapt to extreme temperature changes in both indoor and outdoor industrial sites.
    • The relative humidity tolerance is 5% to 95% non-condensing. Its dimensions are 222.25mm x 88.90mm x 38.10mm and it weighs 0.72kg.

• Technical Specifications
  • Mechanical and Power Parameters
    • It adopts a single-slot design compatible with the Controllogix 1756 backplane, enabling easy installation into Controllogix chassis without occupying excessive space.
    • The backplane current load reaches 800 mA under 5 VDC and 3 mA under 24 VDC, matching the power supply requirements of Controllogix systems for stable operation.
  • Communication Parameters
    • It is equipped with a 10/100 Mbps Ethernet interface with auto-crossover detection, using an RJ45 connector suitable for Cat5 cables, and it supports Ethernet/IP pass-through communication.
    • It supports storage and transfer of up to 5000 16-bit registers with the Controllogix processor through block transfer or side-connect interface. Client parameters are configurable, including a minimum response delay ranging from 0 to 65535 milliseconds, and it also supports floating-point data types.
  • Environmental and Display Parameters
    • The operating temperature ranges from 0 °C to 60 °C, and the storage temperature ranges from -40 °C to 85 °C. It can operate normally in 5% to 95% relative humidity environments without condensation.
    • It is equipped with a 4-character scrolling alphanumeric LED display that shows module version, IP address, application port settings and error information, along with LED indicators for module status, application status and error status.

Core Function

• Protocol Conversion: Bridges EtherNet/IP (CIP, PCCC) and Siemens Industrial Ethernet protocols for seamless interoperability between Rockwell controllers and Siemens PACs .
• Data Exchange: Supports high-speed bidirectional transfers of up to 10,000 16-bit registers, ideal for large-scale industrial data synchronization .
