Honeywell HCIX15-TE-FA-NC

Product Name: Honeywell HCiX Series 15-inch Industrial Touchscreen HMI (Human-Machine Interface)

Product Introduction:

A rugged panel-mount operator terminal for real-time visualization, control, and data logging in industrial automation, process plants, and machinery lines.

Category: Honeywell

Description

Technical Specifications:

Display: 15″ TFT LCD, 1024 × 768 (XGA), 256 colors
Touch: Resistive analog single-touch
Processor: 32-bit RISC / Intel Atom dual-core (~1 GHz)
Memory: 1 GB RAM, 32 GB SSD (or 512 MB Flash)
Ports: 1× Ethernet 10/100, 1× RS-232C, 1× RS-422/485, 2× USB 2.0
Power: 24 V DC ±10%, 1.5 A (36 W)
Backlight: LED, >50,000 hrs
Front Panel: IP65 sealed bezel
Enclosure: Heavy-duty metal
Dimensions: 350 × 280 × 60 mm
Weight: ~4.5 kg
Temp (Op): -10 °C to +60 °C
Humidity: 10%–90% non-condensing
Certifications: CE, UL, cUL

Functional Features:

Supports PLC/DCS/SCADA integration (Siemens, Rockwell, Schneider, Honeywell)
Onboard data logging, recipe management, alarm/trend display
Multi-language HCi Design Studio (HDS) configuration

Application Scenarios:

Oil & gas wellhead/pipeline stations
Power generation plants (thermal, hydro, renewable)
Chemical, water/wastewater, pharma GMP lines, F&B production

Structure & Material:

Powder-coated steel rear housing, tempered glass front with resistive film
Gasket-sealed bezel for panel mounting

Working Principle:

Runs embedded HMI runtime that polls connected controllers via fieldbus/ethernet, renders graphical screens, logs operator inputs and process tags, and pushes control commands back to the automation layer.

Installation Requirements:

Cutout per datasheet dimensions, torque clamps evenly
Use IP65-compatible gasket on panel
Isolate from strong RF/EMI sources; use surge-protected 24 V DC

Usage Precautions:

Clean screen with non-abrasive, alcohol-free cloth
Avoid sharp objects on resistive touch
Backup project files before firmware upgrades
