Foxboro H90 H90C9AA0117S - Image 1
Foxboro H90 H90C9AA0117S - Image 2
Click to enlarge
Foxboro H90 H90C9AA0117S
Foxboro H90 H90C9AA0117S - Image 2
Parker GV6K-U6E
Parker GV6K-U6E
Back to products
Schenck FSE-L003
Schenck FSE-L003

Foxboro H90 H90C9AA0117S

  • Product Name: I/A Series H90 Industrial Workstation / Computer Node
  • Product Introduction: A rackmount industrial computer workstation serving as the Human-Machine Interface (HMI), engineering station, or history node within Foxboro’s I/A Series Distributed Control System (DCS).
Category:
Description
  • Technical Specifications:
    • Processor: Intel Xeon E5-2609v3 (or equivalent industrial CPU).
    • Memory: 8GB DDR4 ECC registered (expandable).
    • Storage: 300GB+ Industrial SSD/HDD, redundant capable.
    • OS: Windows Server 2008 R2 (legacy DCS support) or customized real-time OS.
    • Network: 4x Gigabit Ethernet (10/100/1000BaseT).
    • Serial: RS-232 / RS-485 ports.
    • Power: 24 VDC redundant input (some variants 110/220VAC).
    • Environment: -10 to 50°C, shock/vibe resistant, IP65 front (rack).
    • Dimensions: Approx 430 x 300 x 450 mm (rack mount).
  • Functional Features: Real-time process data rendering, alarm management, control logic download/upload, historical data archiving, multi-monitor support, Modbus/Fieldbus protocol stack integration.
  • Structural Features: Heavy-gauge steel chassis, filtered intake fans, lockable front bezel, hot-swappable drive bays (in redundant configs), ISA/PCIe expansion slots for fieldbus cards.
  • Application Scenarios: Central control room operator consoles in oil refineries, power generation DCS nodes, pharmaceutical batch process supervision, large-scale water treatment plant SCADA hosts.
  • Installation Requirements: Install in climate-controlled cabinet (<50°C); ensure UPS-backed 24VDC redundancy; ground chassis to plant earth grid (<1 ohm); maintain spacing for rear I/O clearance; antivirus/whitelisting policies mandatory for Windows-based nodes.
