Technical Specifications & Performance Parameters:
-
Image Sensor: 1/2.3″ Progressive Scan CMOS
-
Resolution & Frame Rate: Max 2992×2992 @ 25/30 fps
-
Lens: Focal length 1.2 mm, Horizontal/Vertical FOV 182°, Stereographic lens with Sharpdome 360 technology
-
Min Illumination: Color 0.19 lux, B/W 0.04 lux
-
WDR: Forensic WDR
-
Lightfinder: Yes (lifelike colors in low light)
-
IR Illumination: Built-in OptimizedIR with individually controllable LEDs (850 nm, range up to 15 m scene dependent)
-
Video Compression: H.264 (Baseline, Main, High), H.265 with Axis Zipstream
-
Audio: Audio support via Portcast tech / I/O (input/output)
-
Local Storage: microSD/microSDHC/microSDXC card slot (NAS support)
-
Network: RJ45 10BASE-T/100BASE-TX PoE (IEEE 802.3af/802.3at Type 1 Class 3), Normal 6.4 W, Max 12.95 W
-
Cybersecurity: Axis Edge Vault, Signed OS, Secure Boot, Device ID (IEEE 802.1AR), Signed Video
-
Analytics: Axis Object Analytics (human/vehicle classification), ACAP v4 support (edge DL apps)
-
Rating: IP66, NEMA 4X, IK10 (Vandal resistant), -40 °C to +50 °C operating
-
Dimensions: Height 70 mm, Diameter 149 mm, Weight 860 g
-
Digital Features: Digital roll (remote rotation adjust), digital PTZ, dewarping (panorama, quad, corridor views)
Material Composition & Structure:
-
Dome Cover: Polycarbonate with hard coating (scratch resistant, impact resistant)
-
Housing Main Body: Aluminum (white, NCS S 1002-B), repaintable cover ring
-
Mounting Bracket: Pre-drilled for junction boxes (single/double gang, 4″ octagon), UNC 1/4″ tripod thread
-
Internal: ARTPEC-8 SoC with DLPU, CMOS sensor module, IR LED array, I/O terminal block
Functional Features & Working Principle:
-
Working Principle: Captures ultra-wide fisheye/distorted images via stereographic lens, then uses onboard processing to dewarp the image into usable panoramic, quad, or corridor views, or provides raw 360° stream for client-side dewarping.
-
Deep Learning on Edge: DLPU processes metadata for object classification without heavy server load, enabling efficient forensic search.
-
Axis Edge Vault: Hardware-based security storing device ID and keys to prevent unauthorized access and ensure supply chain integrity.
-
Digital Roll: Software adjustment of image orientation post-installation, avoiding physical camera rotation.
-
Zipstream: Analyzes video streams to prioritize important details and compress irrelevant areas, drastically reducing bandwidth/storage.
Application Scenarios:
-
Retail stores, supermarkets (wide area aisle monitoring)
-
Open-plan offices, lobbies, reception areas
-
Warehouses, logistics centers (overview of loading docks)
-
Public transportation hubs (stations, terminals)
-
School corridors, hospital waiting rooms
Installation Requirements & Usage Notes:
-
Factory focused for ease; check focus is locked before final install.
-
Mount on a flat surface or junction box; use supplied gaskets to maintain IP66 rating.
-
Avoid mounting directly facing intense light sources (sun, spotlights) to prevent glare in fisheye lens; plan placement for optimal coverage.
-
Use PoE+ (802.3at) switch if IR and full features are active simultaneously to meet max power budget.
-
Format SD card in-camera before use; unmount via web interface before removal to prevent data corruption.
-
Do not use harsh chemicals (acetone, window cleaner) to clean the dome; use lukewarm water and soft cloth to avoid damaging coatings.
-
Ensure IK10 rating is maintained by using supplied tamper-proof screws.
