Technical Specifications & Performance Parameters:
-
Product Model: M10-1GB-SFP-B (Internal Code: 3HE01616AA)
-
Data Rate: 1.25 Gbit/s (1000 Mbps, Gigabit Ethernet)
-
Form Factor: SFP (Small Form-factor Pluggable) / MSA-compliant
-
Interface: Duplex LC connector (for optical variants) or RJ45 (for copper SFP)
-
Fiber Support: Compatible with Single-mode (SMF) and Multi-mode (MMF) fibers
-
Transmission Distance: Dependent on SFP inserted; 550 m (MMF OM2/OM3), up to 10 km/40 km/80 km (SMF depending on wavelength/class)
-
Diagnostic: Digital Diagnostic Monitoring (DDM/DOM) per SFF-8472 (Temperature, Bias, Tx/Rx Power, Voltage)
-
Management: SNMP v3, RMON statistics, compatible with Alcatel-Lucent 5620 SAM
-
Hot-Pluggable: Yes, supports live insertion/removal without powering down host
-
Operating Temperature: 0 °C to 45 °C (commercial grade typical)
-
Power Supply: From host device (typically 3.3 V)
Material Composition & Structure:
-
Housing: Metal enclosure (EMI shielding) with nickel or zinc plating
-
Connector: Ceramic ferrule LC duplex interface (optical) or RJ45 PCB-mounted (copper)
-
PCB: Multilayer FR4 with high-speed differential pair routing
-
Optical Subassembly: TOSA (Transmitter Optical SubAssembly) and ROSA (Receiver Optical SubAssembly) containing laser diode (FP/DFB) and photodiode
Functional Features & Working Principle:
-
Working Principle: Converts serial electrical signals from the host board into optical signals (or vice versa) using laser/LED modulation and photodetection, or performs electrical signaling for copper links.
-
Flexible Media Adaptation: Open SFP slot allows users to select transceivers based on distance and media type, reducing spare inventory costs.
-
Intelligent Diagnostics: Monitors real-time operational parameters and reports via I2C two-wire serial interface for proactive fault management.
-
Dual Redundancy Support (in module context): Some interpretations include support for redundant power/path in chassis modules.
Application Scenarios:
-
Data center interconnects and server connectivity
-
Enterprise campus network backbones
-
Metropolitan Area Networks (MAN)
-
Service provider access and aggregation networks
-
Storage Area Networks (SAN) at 1G speeds
Installation Requirements & Usage Notes:
-
Ensure the inserted SFP transceiver matches the port speed and fiber type (single-mode vs multi-mode mismatch causes link failure or damage).
-
Use proper ESD precautions when handling the module; hold by the edges.
-
Do not look directly into the optical ports when the transmitter is active (invisible laser light hazard).
-
Verify compatibility with the specific Alcatel-Lucent chassis/router IOS version if used as a line card/module.
-
Keep dust plugs on unused ports to prevent contamination of optical connectors.
