The IC693CPU363 is a single‑slot modular CPU module from GE Fanuc (now part of Schneider Electric) for the Series 90‑30 PLC platform, powered by a 25 MHz 80386EX 32‑bit processor. It has 240 KB user program memory, a 0.22 ms/1K Boolean scan rate, and supports up to 8 baseplates (1 CPU + 7 expansion/remote). The module provides 2048 discrete I/O points each, 2048 analog input words, 512 analog output words, and 32‑bit floating‑point math. It features three serial ports (2 onboard + 1 via power supply) with SNP/SNP‑X master/slave and RTU slave protocols, enabling seamless programming, diagnostics, and HMI/SCADA integration. Compatible with PCM/CCM specialty modules, it serves as a scalable core for medium‑to‑large automation systems requiring high processing performance and flexible expansion. RAM is backed by a battery for program/data retention during power loss.

The IC693MDL340 is a 16‑channel discrete output module from GE Fanuc (now part of Schneider Electric) for the Series 90‑30 PLC platform, delivering 120VAC relay outputs divided into two isolated groups of 8 channels each. Each group has an independent common terminal, supporting separate AC phases or shared power for flexible field wiring. It features 1500V isolation between field and logic sides, 500V group‑to‑group isolation, 0.5A per‑point/3A per‑group current capacity, and 20A inrush per cycle for inductive/incandescent loads. Built‑in 3A group fuses and RC snubbers protect against transients, while a 5V backplane draw of 315 mA ensures compatibility with Series 90‑30 power supplies. It serves as a robust interface for controlling industrial actuators, valves, and motor starters in harsh environments.

The IC693MDL655K is a high-density discrete input module tailored for the GE Fanuc Series 90-30 PLC system, engineered to collect 24VDC discrete input signals from industrial field devices. It features 32 input points split into four isolated groups of eight, each with an independent common terminal, supporting both positive and negative logic for versatile device integration. The module provides 1500 VDC isolation between the field and logic sides, plus 250 VAC isolation between groups, ensuring operational safety in harsh industrial environments. It incorporates individual LED indicators for each input point, a 32-screw removable terminal block for secure wiring, and optocoupler-based isolation for noise immunity. It draws 195 mA max from the 5 VDC backplane and 224 mA typical from the 24 VDC isolated bus, and fits any I/O slot of Series 90-30 baseplates, making it ideal for large-scale signal acquisition with high isolation and flexible grouping.

The IC693MDL730 is an 8‑channel discrete output module from GE Fanuc (now part of Emerson Automation) for the Series 90‑30 PLC platform, providing 12/24VDC positive logic transistor outputs in a single group with a shared common terminal. It uses 1500V field‑to‑logic isolation to protect against noise and transients, supports 2A per‑channel current capacity, and offers 9.4A inrush current for 10 ms to handle inductive loads. The module has a 2A group fuse at 60°C (4A at 50°C) for overload protection, a 5V backplane power draw of 120 mA, and operates with an external 12/24VDC supply (10.2–28.8VDC range). It serves as a high‑current interface for controlling industrial actuators, solenoids, and motor starters in harsh environments.
