GE IC200PBI001
Technical Specifications:
- Communication Protocol: Profibus-DP
- Network Interface: RS-485
- Baud Rate: Supports multiple baud rates, including 9.6 Kbps, 19.2 Kbps, 93.75 Kbps, 187.5 Kbps, 500 Kbps, 1.5 Mbps, 3 Mbps, 6 Mbps, and 12 Mbps.
- Data Packet Size: Up to 244 bytes
- Power Supply: 24 VDC
- Dimensions: 80 x 45 x 25 mm
- Weight: 0.2 kg
GE IC200MDL940K
Technical Specifications:
- Output Points: 16 discrete outputs, divided into two groups of eight outputs each.
- Output Type: Relay outputs with fixed coils and moving armatures.
- Contact Material: Silver contacts for improved conductivity and durability.
- Load Current: Minimum load current of 10 mA per point; maximum load current varies based on voltage conditions:
- 2 A per point for AC voltages from 5 to 265 V.
- 2 A per point for DC voltages from 5 to 30 V.
- 0.2 A per point for DC voltages from 31 to 125 V.
GE IC200MDL742
Technical Specifications:
- Output Points: 32 discrete outputs (two groups of 16 outputs each).
- Output Type: Positive logic outputs.
- Load Current: 0.5 A per output point.
- Voltage Range: Supports a wide voltage range for compatibility with various power sources.
- LED Indicators: Each output point is equipped with an LED indicator for visual status monitoring.
- Terminal Block: Removable terminal block for easy wiring and maintenance.
- Environmental Resistance: Designed to withstand harsh industrial conditions, including temperature extremes and vibration.
GE IC200MDL650
Technical Specifications:
- Input Channels: 32 non-isolated inputs, divided into four groups of eight channels each.
- Voltage Ratings:
- Nominal operating voltage: 240 VAC.
- Operating voltage range: 0 to 264 VAC.
- On-state voltage range: 155 VAC to 264 VAC.
- Off-state voltage range: 0 to 40 VAC.
- Input Current: 2.0 to 5.5 mA.
- Backplane Current Consumption: 50 mA.
GE IC200MDL241
Technical Specifications:
- Input Channels: 16 non-isolated inputs, divided into two groups of eight channels each.
- Voltage Ratings:
- Nominal operating voltage: 240 VAC.
- Operating voltage range: 0 to 264 VAC.
- On-state voltage range: 155 VAC to 264 VAC.
- Off-state voltage range: 0 to 40 VAC.
- Current Consumption:
- Maximum backplane current consumption: 110 mA at 110.0 V.
- Maximum operating current: 5.0 mA at 110.0 V from the backplane.
GE IC200MDD844
Technical Specifications:
- I/O Points: Provides a total of 32 I/O points, divided into 1 group of 16 outputs and 2 groups of 8 inputs each.
- Output Types: Supports two types of outputs - positive logic and sourcing, enabling the module to supply DC voltage to loads.
- Input Types: The 32 input points are of positive logic type, allowing them to draw current from connected devices and return it to the common wire.
- Input Voltage Range: 0 to 30 volts.
- Output Voltage Range: 10.2 to 30 volts.
GE IC200GBI001
Technical Specifications:
- I/O Capacity: Supports up to 64 I/O modules (8 modules per rack, with a maximum of 8 racks).
- Memory: 1024 discrete input points, 1024 discrete output points, 128 bytes of analog input memory, and 128 bytes of analog output memory.
- Transmission Speed: Supports up to 153.6 kbaud for extended network configurations, with standard speeds of 153.6 kbaud, 76.8 kbaud, and 38.4 kbaud.
- Bus Connections: Dual Genius bus terminals (upper terminal for primary connection, lower terminal for redundancy).
- Power Consumption: 250 mA at 4VDC and 10 mA at 3.3VDC.
GE IC200EBI001-NJ
Technical Specifications:
- Bus Connections: Two Genius bus connections (upper terminals for primary connection, lower terminals for redundancy).
- Transmission Speed: Supports up to 38.4 Kbaud for standard configurations and up to 153.6 Kbaud for extended network configurations.
- I/O Capacity: Each rack can accommodate up to eight I/O modules, with support for up to eight racks (64 I/O modules in total).
- Memory: 1024 points of discrete input memory, 1024 bytes of discrete output memory, 128 bytes of analog input memory, and 128 bytes of analog output memory.
GE IC200CPUE05
Technical Specifications:
- Processor: High-performance 32-bit processor.
- Memory: 64KB user-configurable memory for program storage.
- I/O Capacity: Supports up to 64 modules, expandable to 2048 I/O points.
- Communication Interfaces:
- RS-232 for local programming and debugging.
- RS-485 for Modbus RTU master/slave communication.
- Ethernet (10Mbps, half-duplex or full-duplex) for remote monitoring and data exchange.
GE IC200CHS022
Technical Specifications:
- Slots: 2 slots for installing IC200 series modules (e.g., CPU, power supply, or I/O modules).
- Mounting: DIN-rail mounting (TS-35/7.5 or TS-35/15 standard).
- Backplane: Built-in electrical backplane for automatic power and data signal connections between modules, eliminating the need for additional jumpers.
- Terminals: Pluggable screw-type terminal blocks for easy and quick wiring and maintenance. Some models support pre-wired terminals.
- Dimensions: 16.5 x 6.5 x 7 cm.
- Weight: 0.24 kg.
GE IC200CHS002K
Technical Specifications:
- Terminal Configuration: 36 IEC box-type terminals arranged in two groups (A1-A18 and B1-B18).
- Voltage Range: Supports up to 0-264 VAC, with a transient voltage tolerance of up to 300 VAC.
- Current Capacity: Each terminal rated for 2 Amps, with 8 Amps per power/ground terminal.
- Wire Compatibility: Accepts solid or stranded copper wires ranging from AWG #14 to AWG #22.
- Installation: Designed for horizontal mounting only, with a minimum enclosure depth requirement of 70 mm.
- Backplane Communication: Provides communication and power for hosted I/O modules through a carrier mating connector.
GE IC200ALG331-KD
Technical Specifications:
Output Channels: 4 single-ended analog output channels, each with independent isolation.
Resolution: 16-bit, ensuring high-precision analog output.
Output Signal Types: Supports both voltage and current output signals, including ±10 VDC and 4-20 mA (requires an external 250 Ω resistor for current-to-voltage conversion).
Accuracy: Maximum accuracy of ±0.1% of full scale, ensuring reliable data acquisition.
Update Rate: Each channel has a maximum update rate of 7 milliseconds, enabling fast response to signal changes.
