NI PXIe-1073

NI PXIe-1073

Product Name: PXIe-1073 5-Slot PXI Express Chassis

Introduction: Compact, quiet PXIe chassis with 3 hybrid slots and 2 PXIe slots, up to 250 MB/s system bandwidth, for bench or portable PXIe systems.

Category: NI

Description

Technical Specifications:

Slots: 5 (3 PXIe hybrid, 2 PXIe peripheral)
System bandwidth: 250 MB/s (PXIe Gen1 x1 class backplane)
10 MHz REF and 100 MHz differential clock
Per-slot cooling: 38 W
AC input: 100–240 VAC
Dimensions: standard 3U height, ~257 mm wide

Materials: Aluminum chassis, steel rear bracket, plastic fan shroud.

Working Principle: PXIe point-to-point PCIe links plus shared timing backplane.

Installation: Benchtop; optional rack ears; embedded controller or MXI-E link.

Notes: Hybrid slots accept PXI or PXIe modules; do not block left-side intake; 38 W/slot is not sufficient for very high-power RF modules.
