Technical Specifications:
- Input Signal: 4–20 mA DC (2-wire or 4-wire)
- Output Signal: 4–20 mA DC or 1–5 V DC (selectable)
- Isolation Voltage: 1500 V DC between input, output, and power
- Power Supply Voltage: 24 V DC (nominal), range 18–30 V DC
- Accuracy: ±0.1% of span (typical)
- Response Time: < 100 ms (typical)
- Operating Temperature: -20°C to +70°C (-4°F to +158°F)
- Storage Temperature: -40°C to +85°C (-40°F to +185°F)
- Humidity: 5% to 95% RH (non-condensing)
Functional Features:
- Signal Isolation: Full galvanic isolation between field side and system side
- Signal Linearization: Supports linear 4–20 mA input without additional linearization
- Noise Filtering: Built-in low-pass filter with 4 Hz cutoff frequency (configurable)
- Fault Detection: Open-circuit and short-circuit input detection with diagnostic LED indicators
- Loop Power: Provides 24 V DC loop power to 2-wire transmitters (up to 500 Ω load)
Material Composition:
- Housing: Flame-retardant ABS plastic (UL 94 V-0 rated)
- Terminal Blocks: Phosphor bronze with gold plating
- PCB: FR-4 epoxy glass with conformal coating
- Connectors: Standard Euro-style terminal blocks, screw-clamp type
Structural Characteristics:
- Form Factor: DIN rail mountable module
- Dimensions (W x H x D): 25 mm x 120 mm x 110 mm (approximate)
- Weight: Approximately 150 grams
- Mounting: Standard 35 mm DIN rail (EN 60715)
Working Principle:
The RC27-1840 receives a raw 4–20 mA signal from a field transmitter. The input signal passes through an isolation amplifier that provides galvanic separation. The conditioned signal is then scaled, filtered, and output as a standardized 4–20 mA or 1–5 V signal to the I/A Series controller. The module derives its operating power from the 24 V DC bus and simultaneously provides loop power to the field transmitter.
Advantages / Highlights:
- High isolation rating of 1500 V DC ensures noise immunity and ground loop elimination
- Built-in loop power supply eliminates need for external power for 2-wire transmitters
- Compact DIN rail form factor saves panel space
- Diagnostic LEDs provide immediate fault visibility
- Wide operating temperature range suitable for harsh industrial environments
Applicable Industries:
- Oil and Gas (upstream/midstream/downstream)
- Chemical and Petrochemical Processing
- Power Generation (fossil and nuclear)
- Water and Wastewater Treatment
- Pulp and Paper
- Mining and Minerals Processing
Installation Requirements:
- Mount on 35 mm DIN rail inside the I/A Series I/O cabinet
- Maintain minimum 10 mm clearance above and below the module for ventilation
- Ensure 24 V DC power bus is connected to terminals P+ and P-
- Field wiring connects to IN+ and IN- terminals
- System output connects to OUT+ and OUT- terminals
- Use shielded twisted pair cable for all analog signal connections
- Ground the cable shield at one end only (system side)
Usage Precautions:
- Do not exceed 30 V DC on the power supply input
- Do not connect voltage signals to current input terminals (will damage the module)
- Verify correct input range configuration before commissioning
- Ensure proper torque on terminal screws (0.5–0.8 Nm)
- Replace the module immediately if diagnostic LED indicates fault
