Manufactured in the United States, the cable features a robust 75 Ω triaxial construction with fluoroethylene propylene insulation, ensuring exceptional durability and signal integrity in harsh industrial environments. The armored design with connector protectors provides enhanced mechanical strength and protection against environmental hazards, while the patented cable loc method delivers strong pull strength to secure the cable-probe connection. It is equipped with gold connectors that ensure superior electrical conductivity and corrosion resistance, maintaining stable data transmission over its lifespan. With an 8-meter length, the cable offers flexible installation options, easily integrating into existing industrial infrastructure. It is fully compatible with 3300 XL transducer systems and backward-compatible with non-XL 3300 series components, ensuring seamless interchangeability and reducing replacement complexity.
- Manufacturer: Bently Nevada
- Product Series: 3300 XL
- Product Type: Armored extension cable
- Cable Length: 8.0 meters (26.2 feet)
- Compatibility: 3300 XL 8mm proximity probes, proximitor sensors; backward-compatible with non-XL 3300 series 5mm/8mm components
- Core Application: Vibration and static position measurement
- Linear Range: 0.25 mm to 2.0 mm
- Sensitivity: 1 μm
- Output Type: Voltage (proportional to probe-to-target distance)
- Installation Type: Non-contact
- Termination Type: Gold connector
- Cable Construction: 75 Ω triaxial with FEP insulation; armored with connector protectors
- Capacitance: 69.9 pF/m (21.3 pF/ft) typical
- Operating Temperature Range: -40 °C to +100 °C
- Power Supply: -17.5 Vdc to -26 Vdc
- Maximum Power Consumption: 12 mA
- Output Resistance: 50 Ω
- Field Wiring Compatibility: 0.2 to 1.5 mm² (16 to 24 AWG)
- Pull Strength: 330 N (75 lbf) via patented cable loc method
- Dimensions: 81.3 mm × 50 mm × 63.5 mm
- Weight: 0.272 kg
- Certifications: ISO 9001, CE; compliant with API 670 standard (4th edition)
- Warranty Period: 12 months
- Country of Origin: United States
- Armored construction with connector protectors and FEP insulation ensures resistance to mechanical damage, corrosion, and harsh industrial conditions
- Patented cable loc method provides strong pull strength, securing the cable-probe connection against accidental dislodgment
- Gold connectors deliver optimal electrical conductivity and corrosion resistance, eliminating signal degradation for reliable data transmission
- 75 Ω triaxial design minimizes electromagnetic interference, preserving the accuracy of vibration and position measurement data
- Non-contact installation reduces wear and tear, enabling maintenance-free operation and extending service life
- 8-meter length offers flexible deployment, accommodating diverse industrial setup requirements and standard electrical conduits
- Backward compatibility with non-XL 3300 series components allows seamless integration into existing systems without full infrastructure upgrades
- Compliance with API 670 standard ensures adherence to industry benchmarks for mechanical configuration, accuracy, and temperature stability
- Optional fluid loc feature prevents leakage of oils and other fluids through the cable, enhancing protection in lubricated machinery applications
- High sensitivity of 1 μm enables detection of even minor vibrations, supporting early fault identification and proactive maintenance
- Steam Turbines: Specifically engineered for vibration and position monitoring of steam turbines, withstanding high-temperature operating conditions and ensuring stable performance
- Power Generation: Deployed in thermal, hydropower, and nuclear power plants to monitor generators, turbines, and auxiliary equipment, safeguarding critical power infrastructure
- Fluid-Film Bearing Machines: Ideal for measuring position and vibration in machinery equipped with fluid-film bearings, supporting optimal lubrication and bearing health management
- Compression Systems: Used in industrial compressors to monitor dynamic performance, preventing costly downtime and optimizing compression efficiency
- Speed and Keyphasor Measurement: Supports keyphasor reference and rotational speed measurements for rotating machinery, enabling precise motion analysis
- Heavy Manufacturing: Integrated into production lines for monitoring pumps, motors, and gearboxes, enhancing process reliability and reducing maintenance costs
- Hazardous Industrial Environments: Suitable for use in settings with extreme temperatures, mechanical stress, or fluid exposure, thanks to its armored and insulated construction
- Oil and Gas Industry: Complies with API 670 standards, making it suitable for upstream, midstream, and downstream oil and gas equipment monitoring
- Automation Systems: Seamlessly integrates with DCS and SCADA systems via supported communication protocols, enabling centralized real-time machinery condition monitoring
- Retrofit Projects: Backward compatibility allows easy replacement of older extension cables in existing 3300 series systems, upgrading performance without full system overhauls
