Bachmann IPC1412 - Image 1
Bachmann IPC1412 - Image 2
Click to enlarge
Bachmann IPC1412
Bachmann IPC1412 - Image 2
Vibro-Meter IPC704 244-704-000-042
Vibro-Meter IPC704 244-704-000-042
Back to products
Dixell IPG315D
Dixell IPG315D

Bachmann IPC1412

  • Product Name: Industrial PC / M1 System CPU Module
  • Product Introduction: A robust industrial computing unit part of Bachmann’s M1 automation system, often used as the central controller in wind turbines and process plants.
Category:
Description
  • Technical Specifications & Performance Parameters:
    • Processor: Intel Atom D525 Dual-Core 1.8GHz (or Celeron variant).
    • Memory: 1 GB DDR3 RAM (onboard).
    • Storage: 8 GB Industrial CompactFlash (CF).
    • Interfaces: 2 x Gigabit Ethernet, 1 x RS232/485, 1 x CAN, 2 x USB 2.0, 1 x DVI-I.
    • Power: 24 VDC via M1 backplane (18-34V range).
    • Environment: -25°C to +60°C (fanless convection cooling).
  • Functional Features:
    • Programming: IEC 61131-3 (M1 Toolkit), C/C++, .NET support.
    • Expansion: Connects to M1 backplane for digital/analog/safety I/O modules.
    • OS: Windows XP Embedded (XPE) or Linux RT.
  • Application Scenarios: Wind turbine nacelle control, offshore platform automation, hydroelectric plant supervision.
  • Material & Structural Features: Metal housing for EMC protection, IP20 (cabinet mount), DNV GL marine certified.
  • Working Principle: Runs deterministic control loops on the Atom processor, exchanges I/O data via the M1 backplane bus, handles HMI/SCADA communication via Ethernet, and logs data to CF storage.
  • Installation Requirements: Mount on M1 standard DIN rail backplane; ensure cabinet ventilation for fanless operation; connect protective earth securely.
  • Usage Notes: CF cards have write-cycle limits; avoid excessive frequent logging to extend life. Use industrial-grade CF only. Keep firmware updated for security patches in networked environments.
