Alstom PIB100G

Product Name: Alstom PIB100G (3BEE0226) Process Interface Board / I/O Signal Conditioning Card

Product Introduction:

This is a high-density process signal interface PCB designed for ABB Advant OCS / Alstom Alspa P320 DCS systems. It provides electrical isolation, buffering, and signal conditioning between field I/O wiring (analog or digital) and the system backplane, protecting the CPU from transient surges and ground loops.

Category: ALSTOM

Description

Key Technical Specifications:

Compatible Systems: ABB Advant OCS, Alstom Alspa DCS platforms
Backplane Supply Voltage: +5 V DC (via rack), auxiliary 24 V DC possible depending on I/O type
Isolation: Channel-to-channel and channel-to-backplane high-voltage isolation (typically ≥500 Vrms)
Signal Types Supported: AI (4–20 mA, TC, RTD via external termination), DI (24/48/125 VDC dry/wet contacts)
Operating Temperature: 0 °C to +55 °C (typical DCS cabinet environment)
Construction: Multi-layer FR4 PCB, gold-plated edge connector, conformal coating option
Certifications: CE, IEC 61131-2EMC compliance

Functional Features:

Galvanic isolation to suppress ground potential differences
High common-mode rejection ratio (CMRR)
Supports hot-swap in compatible racks (system dependent)

Application Scenarios:

Power generation (coal, gas, hydro) turbine & boiler I/O, petrochemical process plants, pulp & paper DCS cabinets.

Installation Notes:

Insert only into designated Alstom / ABB Advant rack slot
Verify jumper / DIP-switch settings match field signal type before energizing
Ensure proper rack grounding to maintain isolation integrity
