The IC660BBD024 is an intelligent, configurable I/O block from the GE Genius I/O series, now under Emerson Automation . This module serves as a compact interface between a controller and field devices that send or receive binary signals. It features 32 identical discrete circuits, each configurable as an input, output, or output with feedback, providing exceptional application flexibility . The block is specifically a sourcing type, meaning it sends current to field output devices such as relays, contactors, lamps, and low-power control devices .

Product Introduction This configuration identifies the IC660ELB921H as a relay output module for industrial automation systems. It provides control signals for various field devices through normally open contact relays. The module supports CPU redundancy and is configurable via PCIM Configuration Software, designed for integrating control outputs within GE automation architectures.

Technical Specifications:

• Input/Output Configuration: The module supports a combination of digital inputs and outputs, with a typical configuration of 8 outputs.
• Output Type: Transistor outputs (sourcing or sinking, depending on configuration).
• Output Voltage: 24 VDC.
• Output Current: Each output point can handle a maximum of 0.5 A (sinking) or 0.3 A (sourcing).
• Response Time: The typical response time is less than 1 ms, ensuring real-time control and monitoring.
• Isolation Voltage: The module provides 500 VAC isolation between the field side and the logic side, enhancing system safety and reliability.

Technical Specifications

• Number of Channels: 8 single-ended analog input channels
• Input Signal Types: Accepts 0-20 mA and 4-20 mA current signals
• Resolution: 12-bit digital resolution for accurate signal representation
• Conversion Time: 1 microsecond per channel at a 60 MHz module clock frequency
• Input Impedance: 2.87 kilohms
• Isolation: Each channel has ground and logic isolation rated at 1500 VAC for one minute and 250 VAC continuously

Product Description The GE IC670ALG240-JC is a high-performance analog input module manufactured by GE Fanuc, belonging to the Field Control series . Its primary function is to convert analog current signals from field sensors or transmitters into digital signals that a programmable logic controller can process . The module is designed for integration with GE Fanuc Series 90-30 and Series 90-70 PLC systems .
