GE IC693ALG222
Technical Specifications:
- Input Type: Analog voltage input
- Number of Channels: 16 single-ended or 8 differential channels
- Input Range: Configurable for various voltage ranges, typically including 0-10V, ±10V, and other industry-standard ranges
- Resolution: 12-bit digital resolution for accurate signal conversion
- Accuracy: ±0.1% of full scale for precise measurements
- Conversion Time: Fast conversion rate, typically less than 1 ms per channel
GE IC676PBI016
GE IC670ALG230
Technical Specifications:
- Input Channels: 8 single-ended analog current input channels.
- Supported Signal Ranges: Configurable for 0–20 mA or 4–20 mA current loops.
- Resolution: 12-bit digital resolution; 5.0 μA analog resolution.
- Conversion Time: 60 μs per channel (typical) under a 1 MHz module clock.
- Input Impedance: 2.87 kΩ.
- Isolation: Each channel provides ground and logic isolation rated at 1500 VAC for 1 minute (continuous 250 VAC).
GE IC660EPM100J
Technical Specifications:
- Input/Output Configuration: The module supports a combination of digital inputs and outputs, with a typical configuration of 8 outputs.
- Output Type: Transistor outputs (sourcing or sinking, depending on configuration).
- Output Voltage: 24 VDC.
- Output Current: Each output point can handle a maximum of 0.5 A (sinking) or 0.3 A (sourcing).
- Response Time: The typical response time is less than 1 ms, ensuring real-time control and monitoring.
- Isolation Voltage: The module provides 500 VAC isolation between the field side and the logic side, enhancing system safety and reliability.
GE IC200UDR064
Technical Specifications:
- Input/Output Configuration: The module supports a combination of digital inputs and outputs, typically featuring 16 points (configurable as input or output).
- Input Specifications:
- Input voltage range: 24 VDC (±25% tolerance).
- Input current: Approximately 3 mA per input.
- Input response time: Less than 1 ms.
GE IC200PWR102E
Technical Specifications:
- Input Voltage: Supports a wide AC input range of 85-264 VAC (single-phase), accommodating global power standards.
- Output Voltage: Provides +5 VDC (logic power) and +24 VDC (sensor/communication power) to meet the power requirements of different modules.
- Output Current:
- +5 VDC output: Up to 2.0 A
- +24 VDC output: Up to 0.8 A
- Total Output Power: Approximately 10 watts.
GE IC200PWR102D
Technical Specifications:
- Input Voltage: Supports a wide AC input range, typically 85-264 VAC (single-phase), accommodating global power standards.
- Output Voltage: Provides 5 VDC and 3.3 VDC outputs to meet the power requirements of different modules within the VersaMax system.
- Output Current: The total output current is rated at 1.5 A, with specific current limits for each output voltage (e.g., 1.0 A at 3.3 VDC and 0.5 A at 5 VDC under certain conditions).
- Power Efficiency: Designed for high efficiency, minimizing energy loss and reducing operational costs.
GE IC200PWR101E
Technical Specifications:
- Input Voltage: Supports a wide AC input range, typically 85-264 VAC (single-phase), accommodating global power standards.
- Output Voltage: Provides 24 VDC output, a standard for PLC systems.
- Output Current: Rated for 10 amps, meeting the power demands of medium-to-large RX3i control systems.
- Power Efficiency: Conversion efficiency ranges from 80% to 95%, minimizing energy loss and reducing operational costs.
GE IC200PWR001G
Technical Specifications:
- Input Voltage: 24 VDC
- Output Voltage: 3.3 VDC and 5 VDC
- Input Power Rating: 10 watts
- Maximum Output Current: 3.3 A at 1 V and 5.5 V rated outputs; total maximum output current of 1.5 A
- Surge Current Rating: 24 A at 20 VDC; 30 A at 25 VDC
- Power Hold-Up Time: Up to 10 milliseconds
GE IC200PWB101D
Technical Specifications:
- Input Voltage: 24 VDC (nominal), with an operating range of 20.4 VDC to 28.8 VDC.
- Output Current: Provides up to 1.5 A of additional current to the backplane, supporting multiple I/O modules.
- Power Consumption: Draws a maximum of 0.3 A from the 5 VDC backplane supply.
- LED Indicators:
- PWR LED: Indicates the presence of 24 VDC input power.
- OK LED: Shows the operational status of the module and the connected power supply.
GE IC200PWB001
Technical Specifications:
- Power Supply: The module supports both AC and DC power inputs, with a voltage range that accommodates various industrial power standards.
- LED Indicators: It features two LED indicators:
- "PWR" LED: Indicates the operational status of the connected booster power supply.
- "OK" LED: Shows the functional status of the NIU or CPU, as well as the connected booster power supply.
- DIN Rail Mounting: Designed for easy installation on 7.5 mm x 35 mm DIN rails, ensuring a secure and organized setup.
GE IC200PBI001
Technical Specifications:
- Communication Protocol: Profibus-DP
- Network Interface: RS-485
- Baud Rate: Supports multiple baud rates, including 9.6 Kbps, 19.2 Kbps, 93.75 Kbps, 187.5 Kbps, 500 Kbps, 1.5 Mbps, 3 Mbps, 6 Mbps, and 12 Mbps.
- Data Packet Size: Up to 244 bytes
- Power Supply: 24 VDC
- Dimensions: 80 x 45 x 25 mm
- Weight: 0.2 kg
