GE IC694PWR330
Product Introduction
The IC694PWR330 is a 30-Watt high-capacity serial expansion power supply module tailored for GE PACSystems RX3i, dedicated to supplying regulated power to serial expansion backplanes. It accepts a wide input range of 85–264 VAC or 100–300 VDC, and delivers three outputs: 5 VDC (30W max) for backplane logic, 24 VDC Relay (15W max) for output relay modules, and 24 VDC Isolated (20W max) for 24 VDC input modules and external devices. It integrates 1500 VAC input-to-backplane isolation, comprehensive protection (overvoltage, undervoltage, overcurrent, short - circuit), and LED indicators for power, output status, and faults. It is a non - hot - swappable module, exclusively for serial expansion backplanes, offering stable supplementary power for distributed RX3i systems in industrial automation applications.
GE IC694MDL660CA-BC
Product Introduction
The IC694MDL660CA-BC is a 32-channel discrete input module for PACSystems RX3i, featuring 4 isolated groups of 8 channels, positive/negative logic per group, and 7 selectable input filter times (0.5–100 ms). It converts 24 VDC field signals (0–30 VDC range) to digital data, with 250 VAC continuous optical isolation (field to backplane) and 250 VAC group-to-group isolation. Each channel has a green LED for ON/OFF status, and the module uses a detachable terminal board (IC694TBB032/IC694TBS032). It supports hot-swap, integrates advanced diagnostics, and operates with RX3i CPUs (release 2.90+), delivering high-density, flexible input acquisition for industrial automation. The CA-BC variant denotes specific manufacturing and compliance standards, ensuring consistency with global industrial certifications.
GE IC694MDL655
Product Introduction
The IC694MDL655 is a 32-channel discrete input module for PACSystems RX3i, designed to monitor 24 VDC field devices with positive/negative logic compatibility and 4 isolated groups of 8 inputs. It converts dry contact, proximity switch, and sensor signals to digital data for PLC processing, integrating 250 VAC optical isolation, 2 ms response time, and individual channel LEDs for status monitoring. Each group has a dedicated common for flexible wiring, and it supports hot-swap for minimal downtime. It delivers high-density, reliable input acquisition for industrial automation, suitable for high-channel-count monitoring in manufacturing, energy, and infrastructure applications.
GE IC694ALG223
Product Introduction
The IC694ALG223 is a 16-channel single-ended analog current input module for PACSystems RX3i/RX7i, converting industrial 4-20 mA, 0-20 mA, and 4-20 mA Enhanced current signals to 12-bit digital data for PLC processing. Each channel is independently configurable, factory-calibrated, and features open-wire detection in Enhanced mode. It integrates 250 VAC optical isolation, high/low alarm limits, and hot-swap capability for mission-critical process and discrete applications. The module uses a detachable terminal board, has two status LEDs (Module OK, User Power), and occupies one chassis slot, serving as a high-density, high-precision solution for industrial signal acquisition.
GE IC693TCM302B
Product Introduction
The IC693TCM302B is an 8-channel temperature control module for the GE Fanuc Series 90-30 PLC system, managing eight independent temperature zones with thermocouple/RTD inputs and PWM discrete outputs. It supports open-loop manual control and closed-loop auto PID control, delivering ±1°C temperature accuracy and 12-bit (0.2°C) resolution. Revision B enhances temperature range and diagnostic capabilities, integrating seamlessly with Series 90-30 PLCs to simplify complex industrial temperature regulation. It features open thermocouple/reverse connection detection, out-of-tolerance monitoring, and programmable PWM outputs (0.1–60 seconds) for precise heating/cooling control, serving as a high-performance solution for multi-zone temperature management in industrial automation.
GE IC693PWR331D
Product Introduction
The IC693PWR331D is a high-capacity 30-watt power supply module designed exclusively for the GE Fanuc Series 90-30 PLC system, installed in the leftmost slot of Series 90-30 baseplates to supply power to CPUs, I/O modules, and peripheral devices. It is a DC-input module that operates on a 24 VDC nominal input with a wide range of 18-30 VDC, delivering three configurable outputs: +5 VDC (max 30 W for high-current logic needs), +24 VDC (relay) for relay output modules, and isolated +24 VDC for input modules and internal circuits. The module integrates overvoltage, overcurrent, and short-circuit protection with auto-shutdown, maintains a 20 ms minimum holdup time during voltage dips, and features four top-mounted LEDs for status monitoring (PWR, OK, RUN, BATT). It includes an RS-485 port for diagnostics and uses a detachable terminal board for simplified wiring, serving as a high-current power solution for Series 90-30 systems requiring enhanced +5 VDC capacity.
GE IC693PWR324
Product Introduction
The IC693PWR324 is a 30-watt AC/DC input power supply module for the GE Fanuc Series 90-30 PLC system, installed in the leftmost slot of Series 90-30 baseplates to power CPUs, I/O modules, and peripheral components. It accepts 85-264 VAC (50/60 Hz) or 100-300 VDC input, delivering three stable outputs: +5 VDC for logic circuits, +24 VDC (relay) for relay output modules, and isolated +24 VDC for input modules and internal circuits. The module integrates overvoltage, overcurrent, and short-circuit protection, with 20 ms minimum holdup time during power dips, and uses a detachable terminal board for field wiring. It features four top-mounted LEDs (PWR, OK, RUN, BATT) for status monitoring, supports RS-485 communication, and operates in 0°C - 60°C environments, serving as a foundational power component for Series 90-30 system integrity.
GE IC693PWR321
Product Introduction
The IC693PWR321 is a standard 30-watt power supply module dedicated to the GE Fanuc Series 90-30 PLC system, designed to mount in the leftmost slot of Series 90-30 baseplates and power the CPU, I/O modules, and peripheral components. It accepts a wide input range of 85-264 VAC (50/60 Hz) or 100-300 VDC, delivering three stable outputs: +5 VDC for logic circuits, +24 VDC (relay) for relay output modules, and isolated +24 VDC for input modules and internal module circuits. The module integrates overvoltage, overcurrent, and short-circuit protection, plus smart switch fusing and advanced diagnostics, ensuring reliable power delivery in industrial environments. It uses six user terminals for input wiring, maintains 20 ms minimum holdup time during power dips, and operates within a wide temperature range, serving as a foundational component for Series 90-30 system power integrity.
GE IC693MDL940L
Product Introduction
The IC693MDL940L is a 16-point normally-open (NO) relay output module belonging to the GE Fanuc Series 90-30 PLC system, tailored to switch both AC and DC loads with 2A per channel and 4A per group common. It is structured into four isolated groups of four output points each, each group having an independent common terminal. The module supports 5-30VDC and 5-250VAC (50/60Hz) field voltages, and provides 1500VDC isolation between the field and logic sides, as well as 500VAC isolation between groups. It is fitted with individual green LED indicators for each output point, uses a 20-pin removable terminal block, and draws 7mA from the 5VDC backplane and 135mA from the 24VDC backplane when all outputs are on. It can be installed in any I/O slot of Series 90-30 baseplates, providing a reliable solution for controlling heavy industrial loads in various automation applications.
GE IC693MDL940
Product Introduction
The IC693MDL940 is a 16-point normally-open (NO) relay output module designed for the GE Fanuc Series 90-30 PLC system, engineered to switch AC/DC loads with 2 A per channel and 4 A per group common. It features four isolated groups of 4 output points each, with independent common terminals, supporting 5-30 VDC and 5-250 VAC (50/60 Hz) field voltages to control devices like motor starters, solenoids, and indicators. The module provides 1500 VDC isolation between field and logic sides and 500 VAC between groups, with individual green LEDs for each output point for real-time status monitoring. It uses a 20-pin removable terminal block, draws 7 mA from the 5 VDC backplane and 135 mA from the 24 VDC backplane (all outputs on), and fits any I/O slot of Series 90-30 baseplates, serving as a robust solution for switching heavy industrial loads.
GE IC693MDL753
Product Introduction
The IC693MDL753 is a 32-point discrete output module dedicated to the GE Fanuc Series 90-30 PLC system, designed to drive 12/24VDC loads through positive (sourcing) logic. It has 32 output points divided into four isolated groups of eight, each with an independent common terminal that can bear up to 3A current per pin. The module can provide 0.5A current per channel and 4A current per group, supporting an inrush current of 5.4A for 10ms to meet the operation of inductive loads. It is equipped with optocouplers that provide 1500VDC isolation between the field side and the logic side to ensure the safety and stability of the system. Each output point is equipped with an individual green LED indicator for real-time monitoring, and it is installed with a 26-screw removable terminal block for easy wiring. It draws 260mA from the 5VDC backplane and can be inserted into any I/O slot of the Series 90-30 baseplate, making it an ideal choice for high-density and high-reliability load control applications.
GE IC693MDL740
Product Introduction
The IC693MDL740 is a 16-point discrete output module tailored for the GE Fanuc Series 90-30 PLC system, designed to drive 12/24VDC loads via positive (sourcing) logic. It features two independent groups of 8 output points with separate common terminals, delivering 0.5 A per channel and 2 A per group common, supporting inrush currents up to 4.78 A for 10 ms to handle inductive loads like relays and solenoids. The module provides 1500 VDC isolation between field and logic sides and 500 VAC between groups, with individual green LEDs for each output point to enable real-time status monitoring. It uses a 20-screw terminal block for secure wiring, draws 110 mA from the 5 VDC backplane, and fits any I/O slot of 5-slot or 10-slot Series 90-30 baseplates, serving as a reliable solution for industrial load control applications.
