GE IC200ALG326H
Technical Specifications:
- Input Channels: 16 single-ended or 8 differential analog input channels, providing flexibility in sensor connection.
- Resolution: 12-bit resolution, ensuring high-precision analog-to-digital conversion.
- Input Signal Types: Supports multiple standard signal types, including ±10 V, 0-10 V, 0-5 V, 0-20 mA, and 4-20 mA (requires an external 250 Ω resistor for current-to-voltage conversion).
- Accuracy: Typical accuracy of ±0.1% of full scale, ensuring reliable data acquisition.
- Sampling Rate: Approximately 200 microseconds per channel, enabling fast response to signal changes.
GE IC200ALG325
Technical Specifications:
- Output Channels: 8 single-ended analog output channels.
- Resolution: 13-bit, ensuring high-precision analog output.
- Output Signal Types: Supports both bipolar and unipolar voltage outputs, including -10 VDC to +10 VDC (bipolar) and 0 VDC to +10 VDC (unipolar).
- Output Current: Each channel can provide a maximum current of 50 mA at 5 VDC.
- Isolation: Provides isolation between user inputs and logic/frame ground, enhancing system reliability and safety.
- Update Rate: 7.5 milliseconds per channel, meeting real-time control requirements.
GE IC200ALG264H
Technical Specifications:
- Input Channels: 15 single-ended analog input channels.
- Resolution: 15-bit digital resolution, ensuring high-precision measurement.
- Input Signal Types: Supports both 4-20 mA and 0-20 mA current signals, covering common industrial sensor signal ranges.
- Analog Resolution: 0.5 μA per count for the 4-20 mA range; 0.625 μA per count for the 0-20 mA range.
- Input Accuracy: Typical value of ±0.5% at an ambient temperature of 0-3°C; maximum full-scale value of ±0.25% at 0-3°C and ±0.6% at 10-0°C.
GE IC200ALG263D
Technical Specifications:
Input Channels: 15 single-ended or 7 differential analog input channels, allowing for simultaneous connection of multiple analog sensors.
Resolution: 24-bit, providing extremely accurate analog data acquisition.
Input Signal Types: Supports both voltage and current modes, including ±10 VDC (bipolar), 0-10 VDC (unipolar), and 4-20 mA current signals.
Input Impedance: 100 kΩ for voltage mode and 250 Ω for current mode.
Isolation: Each channel is isolated from others, enhancing the system's anti-interference ability.
Update Rate: 7.5 milliseconds per channel, ensuring real-time data processing.
GE IC200ALG260
GE IC200ALG230D
Product Introduction:
The GE IC200ALG230D is a high-precision analog input module from the VersaMax series, designed for industrial automation applications. It is specifically tailored for collecting and monitoring sensor signals in industrial environments, ensuring reliable and accurate data acquisition for effective process control.
Technical Specifications:
- Input Channels: 4 single-ended analog input channels.
- Signal Types:
- Voltage: ±10VDC (bipolar), 0-10VDC (unipolar).
- Current: 4-20mA.
- Resolution: 12-bit (4096 levels).
- Sampling Rate: Typical value of 0.4ms per channel, with a filter response of 5ms.
GE Hydran M2-X-O1 S1A2 B2 C0 D0 P1
Product Introduction:
The GE Hydran M2-X-O1 S1A2 B2 C0 D0 P1 is an advanced online dissolved gas analysis (DGA) and moisture monitoring device designed specifically for transformers. It provides continuous monitoring of key parameters such as hydrogen (H₂), carbon monoxide (CO), ethylene (C₂H₄), acetylene (C₂H₂), and moisture content in transformer oil. This enables early fault detection, efficient maintenance management, and minimizes the risk of unplanned outages. The device is part of the Hydran M2-X series, known for its reliability, long sensor life, and ease of integration with various transformer types and digital platforms.
GE Hydran M2 Transformer Monitoring Device
Technical Specifications:
- Gas Detection Range: 0-2000 ppm (equivalent to hydrogen, H₂)
- Humidity Detection Range: 0-100% relative humidity (%RH)
- Gas Detection Accuracy: ±10% of reading ±25 ppm (equivalent to hydrogen)
- Humidity Detection Accuracy: ±2% relative humidity (%RH)
- Gas Detection Repeatability: Better than ±5% or ±5 ppm
- Humidity Detection Repeatability: 2% relative humidity (%RH)
GE IC693CHS397 Modular CPU Backplane
Technical Specifications
- Number of Slots: Five slots for installing I/O modules, one dedicated slot for the power supply module on the far left, and one expansion port.
- Power Supply: The power slot on the left side requires a dedicated power module. The rated current is 170 mA at 5 VDC.
- Expansion Capability: Can be connected to additional expansion baseplates through the 25-pin D-type female expansion connector on the right side, with a maximum cable length of 50 feet (15 meters).
- Compatibility: Supports various GE Series 90-30 I/O modules and special-purpose modules. The number of expandable baseplates depends on the CPU type (e.g., up to four baseplates with CPU 331, 340, and 341, or up to seven baseplates with CPU 350 and above).
GE IC693CHS391 Modular CPU Backplane
Technical Specifications
- Number of Slots: Ten slots for installing modules, including a dedicated slot for the power supply module on the far left.
- Power Supply: Rated current of 420 mA and rated voltage of 5 VDC for the power supply module slot.
- CPU Support: The first slot supports CPU modules marked as CPU/1. The number of additional baseplates supported depends on the CPU type (e.g., up to four baseplates with CPU 341, 340, and 331, or up to seven baseplates with CPU 350).
GE IC693BEM341 FIP Bus Controller Module
Technical Specifications
- FIP Frequency: 2.5 MHz
- Interface Type: Two 9-pin D-type FIP connectors, one RS485 communication port
- Work Voltage: 24V DC (allowable fluctuation range: 19.2V DC – 28.8V DC)
- Current Consumption: Approximately 100mA (at 24V DC work voltage)
- Operating Temperature: 0°C to 55°C
- Storage Temperature: -40°C to 70°C
GE IC693BEM331G Ethernet Communications Module
Technical Specifications
- Network Interface: Dual 10/100 Mbps Ethernet ports with auto-negotiation
- Communication Protocols: Supports TCP/IP, UDP/IP, and GE's proprietary SRTP (Secure Real-Time Transport Protocol)
- Memory: 2 MB of flash memory for firmware and configuration storage
- Power Consumption: 3.5 W typical, 4.5 W maximum
- Operating Temperature: 0°C to 60°C (32°F to 140°F)
- Storage Temperature: -40°C to 85°C (-40°F to 185°F)
