Bently Nevada 350040M 125680-01 4-Channel Proximitor Monitor
Technical Specifications
– Channels : 4 independent, fully isolated
– Input types : eddy-current, velocity, accelerometer
– Measurement modes : radial vibration, thrust position, eccentricity, differential expansion, REBAM, shaft absolute
– Full-scale range : 0 – 10 mm pk-pk or 0 – 50 g (software selectable)
– Frequency response : 0.125 Hz – 3 836 Hz (–3 dB) with direct, gap, band-pass and high-pass filters
– Resolution : 16-bit ADC, <0.02 % non-linearity
– Accuracy : ±0.33 % typical, ±1 % max
– Update rate : 10 kHz per channel
– Alarm relays : 2 per channel (Warning & Danger), latched or unlatched
– Analog outputs : 4 – 20 mA isolated, proportional to measured value
– Power draw : 24 Vdc from rack back-plane, 2.5 W typical
– Sensor supply : –24 Vdc, 50 mA max per channel
– MTBF : >300 000 h @ 45 °C per MIL-HDBK-217F
– Operating temperature : –40 °C to +85 °C
– Storage temperature : –55 °C to +125 °C
– Humidity : 5 % – 95 % RH non-condensing
– Shock / vibration : 15 g ½-sine 11 ms; 2 g 5 – 500 Hz operational
– Dimensions : 99 mm × 24 mm × 241 mm (3.9" × 0.96" × 9.5")
– Weight : 0.34 kg (0.75 lb)
– Agency approvals : CE, UL/cUL Class I Div 2, ATEX/IECEx Zone 2, RoHS
CCC IOC-555-D 17-550555-001 Simplex I/O Card / Communication Control Board
Technical Specifications:
- The module offers 16 serial input/output channels.
- It integrates a processor, memory, and I/O interfaces into a compact form factor suitable for embedded systems.
- It supports high computing performance with low power consumption characteristics.
- Storage options include flash memory and RAM for storing the operating system, applications, and data.
COMPRESSOR CONTROLS PSMU-350-3
Technical Specifications
- Input Voltage: 100-240 VAC, 50/60 Hz (universal compatibility with global power standards).
- Output Voltage: 24 VDC, 5 A (provides stable DC power for downstream devices).
- Power Efficiency: Over 90% conversion efficiency, reducing energy waste and heat generation.
- Operating Temperature: -10°C to +40°C (suitable for industrial environments).
- Storage Temperature: -20°C to +85°C (ensures durability during transportation and storage).
- Dimensions: 120 mm x 58 mm x 35 mm (compact design for space-constrained installations).
- Weight: 200 g (lightweight for easy integration).
COMPRESSOR IOC-555-D
The IOC-555-D is a simplex I/O communication card designed by Compressor Controls Corporation (CCC) for industrial automation systems, particularly in compressor and turbine control applications. While the term "COMPRESSOR IOC-555-D" may imply a standalone compressor, the IOC-555-D is actually a critical component within compressor control systems
CONTROL 9180B-8
- Power Supply: Supports AC 220V/50Hz or DC 24V, depending on design requirements.
- Communication Interfaces: Equipped with RS-485, Ethernet, and Modbus protocols for seamless integration with other devices or systems.
- Processor: High-performance CPU ensures rapid response and accurate control.
- Protection Rating: IP65 or higher for dust and water resistance, suitable for harsh industrial conditions.
- Operating Temperature: Wide temperature range to adapt to diverse industrial settings.
