Kollmorgen CB20560 Servo Drive
Technical Specifications
- Brand: Kollmorgen
- Model: CB20560
- Power Rating: Supports up to 20A continuous current (specific power varies by configuration).
- Input Voltage: Compatible with standard industrial voltage ranges (e.g., 240V AC or 480V AC, depending on region and configuration).
- Feedback Support: High-resolution encoders (e.g., EnDat, Hiperface®, or SFD-M multi-turn absolute encoders).
- Communication Protocols: Supports EtherCAT, CANopen, and other industrial Ethernet protocols for seamless integration.
- Environmental Rating: IP20 (standard); optional IP65 sealing for harsh environments.
- Dimensions: Compact form factor for DIN rail or panel mounting.
- Certifications: Complies with CE, UL, and other international safety standards.
Kollmorgen CB06260 Servo Drive Module
Technical Specifications
- Brand: Kollmorgen
- Model: CB06260
- Power Rating: 220W
- Input Voltage: 220-380V AC
- Output Current: 120A
- Operating Temperature: -20°C to +60°C (standard range; extended ranges may be available)
- Protection Class: IP67 (dustproof and waterproof, suitable for harsh environments)
- Feedback Support: Compatible with EnDat2.2, BiSS, Hiperface®, and resolver feedback systems.
- Communication Protocols: Supports EtherCAT, EtherNet/IP, and Profinet RT for seamless integration with industrial networks.
- Dimensions: Compact form factor for DIN rail or panel mounting.
- Certifications: Complies with CE, UL, and other international safety standards.
Kollmorgen AKM42E-EKGNR-01 Servo Motor
Technical Specifications
- Brand: Kollmorgen
- Model: AKM42E-EKGNR-01
- Type: AC servo motor
- Rated Output Power: 1.14 kW (1.53 HP)
- Rated Speed: 4000 rpm
- Peak Torque: 3.42 Nm
- Encoder: 16-bit resolution, 2-pin hollow shaft
- Protection Class: IP67 (dustproof and waterproof)
- Flange Size: 84 mm × 84 mm
- Voltage: 640 VDC maximum bus voltage
- Physical Dimensions: 31.75 mm height, open keyway shaft, shaft seal, and two M23 straight connectors.
Kollmorgen CB06251 Servo Drive Module
Technical Specifications
- Brand: Kollmorgen
- Model: CB06251
- Power Supply: 24V DC (nominal)
- Output Current: Rated for continuous operation at specified motor current (exact value depends on configuration).
- Feedback Support: Compatible with multi-turn absolute encoders (e.g., SFD-M series) and incremental encoders.
- Communication Interface: Supports industrial protocols such as SynqNet (for high-speed, deterministic control).
- Operating Temperature: -20°C to +60°C (standard range; extended ranges may be available).
- Environmental Rating: IP20 (standard); optional IP65 sealing for harsh environments.
- Dimensions: Compact form factor for DIN rail or panel mounting.
- Certifications: Complies with CE, UL, and other international safety standards.
ABB XO08R1-B4.0 Digital I/O Module
Technical Specifications
- Brand: ABB
- Model: XO08R1-B4.0
- Origin: Europe
- Input/Output Channels: 8 digital inputs and 8 digital outputs
- Communication Protocol: Modbus RTU (standard)
- Power Supply: 24V DC
- Operating Temperature: -40°C to +85°C
- Storage Temperature: -40°C to +85°C
- Environmental Resistance: Dustproof and waterproof (IP67-rated for certain variants)
- Mounting: DIN rail installation for easy integration into control cabinets
- LED Indicators: Visual status display for power, communication, and fault conditions
- Certifications: Complies with international industrial standards (e.g., IEC, UL)
ABB ICSM06A6 PROCONTIC CS 31 Analog I/O Remote Unit
Technical Specifications
- Brand: ABB
- Model: ICSM06A6
- Origin: Sweden
- Input/Output Channels:
- Supports multi-channel analog inputs and outputs for flexible configuration.
- Compatible with temperature sensors, current signals, voltage signals, and standard analog signals.
- Communication Interface: PROCONTIC CS 31 bus for stable data transmission.
- Power Supply: 24V DC input.
- Operating Temperature: -40°C to +85°C.
- Storage Temperature: -40°C to +85°C.
- Environmental Resistance: Dustproof and waterproof (IP67-rated for certain variants).
- Mounting: DIN rail installation for easy integration into control cabinets.
- LED Indicators: Visual status display for power, communication, and fault conditions.
- Certifications: Complies with international industrial standards (e.g., IEC, UL).
ABB ICSE08B5 FPR3346501R1012 DCS/PLC Module
Technical Specifications
- Brand: ABB
- Model: ICSE08B5 FPR3346501R1012
- Origin: Sweden
- Input Voltage: 220V AC
- Output Voltage: 24V DC
- Rated Current: 5A
- Material: Aluminum alloy casing for enhanced durability and heat dissipation
- Protection Features: Overcurrent, overvoltage, and short-circuit protection mechanisms
- Certifications: Complies with international industrial standards (e.g., IEC, UL)
- Operating Temperature: -40°C to +85°C
- Storage Temperature: -40°C to +85°C
- Environmental Resistance: Dustproof and waterproof (IP67-rated for certain variants)
ICS Triplex T9852 High-Performance Industrial Automation Module
Technical Specifications
- Redundancy Architecture: Triple modular redundancy (TMR) with 3-2-0 fault-tolerant operation.
- Input/Output Channels:
- Digital Input: Supports up to 16 channels (e.g., 24V DC, 8-channel or 16-channel configurations).
- Digital Output: 8-channel or 16-channel options available, with each channel supporting up to 1A load.
- Analog Input/Output: Some variants support 8-channel or 16-channel analog inputs/outputs with 16-bit resolution.
- Processor: High-performance processor with speeds ranging from 15-30Hz, enabling real-time control and monitoring.
ICS Triplex T9432 High-Precision Analog Input Module
Technical Specifications
- Input Channels: 16 channels (configurable for 32-channel redundancy via TMR design).
- Input Types: Supports multiple analog signals, including 0-10V, 4-20mA, ±10V, ±5V, ±2.5V, ±1V, 0-20mA.
- Accuracy: ±0.1% FSR (Full Scale Range, typical).
- Sampling Rate: Configurable up to 100 samples per second per channel (typical).
- Resolution: 16-bit.
- Isolation Voltage: 500Vdc (between channels and between channels and system).
- Common-Mode Rejection Ratio (CMRR): >120dB (typical).
- Operating Temperature: -40°C to +70°C.
- Storage Temperature: -40°C to +85°C.
- Humidity: 5% to 95% RH (non-condensing).
ICS Triplex T9402 Controller Module
Technical Specifications
- Redundancy Architecture: Triple modular redundant (TMR) design with three independent CPUs, power supplies, and I/O modules for fault tolerance.
- Processor: 64-bit CPU with a clock speed of ≥1 GHz, enabling high-speed data processing and complex control algorithm execution.
- Memory: RAM ≥2 GB, Flash ≥512 MB, supporting large-scale program storage and rapid data access.
- Input/Output Channels:
- Digital Input: Up to 32 channels (expandable to 128 channels), supporting 0-32 V DC signals.
- Digital Output: Supports relay outputs (max load 2 A/30 V DC).
- Communication Interfaces: Ethernet (10/100 Mbps), RS-485, Profibus-DP, Modbus TCP/RTU for seamless integration with other systems.
- Switching Time: ≤1 millisecond (from fault detection to main-backup switchover).
- Safety Certifications: TÜV SIL 3, IEC 61508, and IEC 61511 compliant, ensuring compliance with international safety standards.
ICS Triplex T9110 Advanced Processor Module
Technical Specifications
- Processor Architecture: Triple modular redundant (TMR) with three independent 32-bit processors executing in parallel.
- Memory: Standard main memory supporting complex logic programs.
- Scan Cycle: High-speed scanning with typical values as low as milliseconds.
- Communication Interfaces: Supports TriBus (TMR bus), ControlNet, EtherNet/IP, Profinet, and Modbus protocols.
- Safety Certifications: IEC 61508 SIL 3, TÜV-certified for safety-critical applications.
- Operating Temperature: 0 °C to 60 °C (standard industrial range).
- Power Supply: 20 V DC to 32 V DC, with redundant power options available.
- Dimensions: Designed for insertion into the leftmost slot of the main system rack.
- Weight: Approximately 2.94 kg (shipping weight: 4 kg).
ICS Triplex T8110B Trusted Triple Modular Redundant (TMR) Processor Module
Technical Specifications
- Processor Architecture: Triple-redundant design with three independent processors running in parallel.
- Voltage Range: 20 V DC to 32 V DC.
- Power Consumption: 80 W (maximum load).
- Processor Clock Speed: 100 MHz.
- I/O Interface: Triple-redundant module-to-module communication bus.
- SOE Buffer Size: 1000 events (expandable to 4000 events in CI buffer).
- Operating Temperature: 0 °C to 60 °C (32 °F to 140 °F).
- Storage Temperature: -25 °C to 70 °C (-13 °F to 158 °F).
- Dimensions (L × W × H): 30.3 cm × 9.3 cm × 26.6 cm.
- Weight: 2.94 kg (shipping weight: 4 kg).
- Communication Protocols: Supports Modbus TCP/IP, Ethernet, and serial interfaces for seamless integration with other systems.
