Yaskawa CACR-SR15BB1BM

Main circuit and control circuit power supply: 3-phase 200–230 V AC, 50/60 Hz

Continuous output current: 11.7 A

Peak output current: 28 A

Matching motor power: 1.5 kW

Feedback support: Incremental encoder, absolute encoder, with pulse rate from 1024 p/r to 8192 p/r

Control method: Three-phase full-wave rectification, IGBT-PWM sine wave drive

Operating temperature: 0°C to 55°C

Storage temperature: -20°C to 85°C

Operating humidity: 20% – 80% non-condensing

Full-digital closed-loop control realizes high-precision position, speed and torque regulation.

Supports flexible switching among speed, position and torque control modes.

Built-in automatic gain tuning function adapts to different load characteristics.

Comprehensive fault protection system covers overcurrent, overvoltage, overload, overheating and encoder abnormality.

Equipped with status display and fault code function for operation and maintenance diagnosis.

Widely used in medium-power automation equipment such as CNC machine tools, industrial robots, injection molding machinery, packaging equipment and printing machinery, providing precise drive control for main motion axes and feed axes to meet high-speed and high-precision motion requirements.

Housing: Aluminum alloy heat dissipation housing

Power stage: IGBT power module

Control circuit: Industrial-grade SMD components on FR-4 PCB

Terminal block: High-current resistant insulating material with copper conductive parts

Book-type metal housing design with integrated heat sink structure improves heat dissipation efficiency.

Front panel is equipped with digital tube and status indicators to display operating parameters and fault codes.

Adopts pluggable terminals for on-site wiring and maintenance.

Internal circuit modular layout with excellent electromagnetic compatibility.

It converts input AC power into DC power through rectifier circuit, and then converts it into controllable three-phase AC power through IGBT inverter circuit to drive the servo motor. Built-in three closed-loop control algorithm collects encoder feedback signals for real-time output adjustment to achieve accurate speed and position control. It interacts with the upper controller through external signal interfaces to receive motion commands and feedback operating status.

Install vertically with at least 50 mm heat dissipation space reserved at the top and bottom.

Power cables and signal cables shall be laid separately with a spacing of not less than 100 mm, and the shielding layer shall be reliably grounded.

Ventilation and heat dissipation devices shall be equipped in the control cabinet to avoid excessive ambient temperature.

Strictly connect power, control and feedback circuits according to the wiring diagram to prevent equipment damage caused by wrong connection.

Must be used with matching Yaskawa servo motor models.

Complete parameter configuration and no-load trial operation before operation.

Do not switch power on and off frequently to avoid impact damage to internal components.

Check regularly the tightening degree of wiring terminals and the patency of cooling channels. Reset operation after troubleshooting according to fault codes.
