SCHNEIDER 416NHM30030A

Series: TeSys GV4 / Compact NSX (depending on catalog year — this is a GV4ME / GV4M series motor protection breaker)

Product Introduction:
The Schneider 416NHM30030A is a 3-pole motor protection circuit breaker rated for 30 A with a thermal-magnetic trip unit. It provides overload protection, short-circuit protection, and phase-loss protection for AC motors.

Category:
Description

Technical Specifications:

Parameter Value
Product Type Motor Protection Circuit Breaker (MPCB)
Poles 3P (3-Pole)
Rated Current (Ir) 30 A
Voltage Rating 690 V AC (Ui) / 500 V AC (Ue)
Breaking Capacity (Icu) 100 kA at 440 V AC
Trip Unit Type Thermal-Magnetic (GV4)
Overload Range 23 – 32 A (adjustable)
Short-Circuit Trip 13 x Ir (390 A) instantaneous
Frequency 50/60 Hz
Utilization Category AC-23A (Motor switching)
Connection Screw terminals (lugs up to 35 mm²)
Mounting DIN rail 35 mm (EN 60715)
Housing Material Glass-fiber reinforced Polyamide (PA66)
Ingress Protection IP20 (front), IP40 (with cover)
Weight Approx. 0.52 kg
Standards IEC 60947-2, IEC 60947-4-1, UL 489

Functional Features:

  • Thermal overload protection — bimetallic strip with adjustable current range
  • Magnetic short-circuit protection — solenoid trip for high fault currents
  • Phase-loss / imbalance protection — trips on single-phasing
  • Trip indicator — red flag shows tripped state
  • Lockable handle — padlock provision for LOTO (Lockout/Tagout)

Applicable Industries:
HVAC, Pumps, Compressors, Conveyors, Machine Tools, Food Processing, Water Treatment

Installation Requirements:

  • Mount on DIN rail EN 60715 (35 mm)
  • Connect motor cables to terminals L1/L2/L3 (top), T1/T2/T3 (bottom)
  • Set overload current using the rotary dial to match motor FLA (Full Load Amps)
  • Ensure adequate ventilation — derate if ambient > 40°C

Usage Notes:

  • Do not use as a general-purpose circuit breaker — this is specifically for motor protection
  • Set overload range to 100–115% of motor rated current
  • Test trip function quarterly
