Reliance 61C22B

Series: Bulletin 61C Series

Product Overview:
The Reliance 61C22B is a magnetic-only motor protection circuit breaker rated for 22A continuous current. It provides short-circuit and ground-fault protection for AC induction motors without overload (thermal) protection. It is a manual-trip, non-adjustable device.

Description

Technical Specifications:

Parameter	Value
Catalog Number	61C22B
Frame Size	61C
Amperage Rating	22A
Voltage Rating	600V AC maximum
Poles	3-pole
Trip Type	Magnetic only (instantaneous) — no thermal overload
Interrupting Rating	10 kA at 480V AC
Horsepower Rating (480V, 3-phase)	10 HP
Horsepower Rating (240V, 3-phase)	5 HP
Enclosure Type	NEMA 1 (indoor, general purpose)
Mounting	Panel mount or DIN rail
Control Voltage	Not applicable (manual trip only)
Auxiliary Contacts	None (basic model)
Terminal Type	Screw terminal, 14–10 AWG
Standards	UL Listed, CSA Certified
Weight	0.45 kg (1.0 lb)

Function Features:

Magnetic-only trip — instantaneous short-circuit protection
No overload protection — must be paired with separate overload relay
10 kA interrupting capacity at 480V AC
Manual toggle handle for ON/OFF operation
3-pole design for 3-phase motor circuits
UL Listed / CSA Certified for North American installations

Applicable Industries:
Machine tools, pumps, fans, compressors, conveyors, general industrial motor control.

Installation Requirements:

Mount vertically in enclosure with adequate ventilation
Wire 14–10 AWG copper conductors to screw terminals
Connect ground wire to ground bar
Must be used with separate overload relay (e.g., 61C-OLR) for motor protection

Usage Notes:

This device does NOT provide overload protection — always install with an overload relay
Use with 600V AC or less
Do not use for DC circuits
Torque terminals to 8–10 in-lb
