MYCOM IMS500-120S

Technical Specifications:

• Motor Type: 2-phase bipolar stepper motor
• Input Voltage: 24 VDC to 80 VDC
• Output Current: 1.2 A to 5.0 A per phase
• Microstep Resolution: Configurable microstep settings
• Control Signal: Differential line driver input (pulse/direction)
• Cooling: Natural convection cooling
• Operating Temperature: 0 °C to +50 °C
• Storage Temperature: -20 °C to +70 °C

Functional Features:

• Adjustable microstep resolution to reduce motor resonance
• Automatic current reduction at standstill to lower heat generation
• Over-current protection, over-voltage protection and motor open-circuit alarm
• Smooth current waveform for low noise operation
• DIP switch configuration for current and microstep setup
• Compatibility with most 2-phase industrial stepper motors

Application Scenarios:

• Semiconductor handling equipment
• PCB assembly machines
• Packaging automation machinery
• Laser processing equipment
• X-Y positioning tables

Performance Parameters:

• Pulse input frequency maximum up to 500 kHz
• Standstill current auto-down function reduces power consumption
• Low torque ripple at fractional microstep operation

Structure Characteristics:

• Compact metal housing for heat dissipation
• Terminal block for power and motor wiring
• DIP switches on front side for parameter setting
• Status LEDs for power and fault indication

Installation Requirements:

• Mount on vertical metal panel for heat dissipation
• Maintain clearance around the unit for air circulation
• Separate motor power wiring from control signal wiring
• Ground driver housing properly

Notes:

• Do not connect or disconnect motor wires while power is active
• Set output current to match motor rated current
• Avoid operating in environments with heavy dust or corrosive gas
