Lenze ESMD113L4TXH509

Product Name: AC Inverter Drive / Vector Frequency Converter
Product Introduction: The Lenze ESMD113L4TXH509 is a 11.0 kW​ high-performance AC drive from the 9300 Vector​ or SMVector​ series, designed for precise motor speed and torque control in demanding industrial applications.
Category:
Description
Technical Specifications:
  • Input Voltage: 3AC 380-480V​ (320-528V), 50/60Hz
  • Rated Power: 11.0 kW​ (15 HP)
  • Output Current: 24A – 27A​ (depending on overload)
  • Overload Capacity: 150%​ rated current for 60 seconds
  • Control Methods: Sensorless Vector Control (SLVC), V/f​ control
    Functional Characteristics: Built-in EMC C2/C3​ filters, DC reactor, brake chopper; supports PID control; vector control without encoder.
    Performance Parameters:
  • Switching Inputs: 4​ digital inputs (dry contact)
  • Analog Inputs: 2​ (0-10V / 4-20mA)
  • Relay Outputs: 2​ (5A @ 250VAC)
  • Analog Output: 1​ (0-10V)
  • Operating Temperature: -10°C to +50°C​ (Derating above 40°C)
  • Protection Rating: IP20
    Material Composition: Metal chassis with aluminum heat sink fins.
    Structural Features: Book-size compact design; dimensions approx 400mm x 250mm x 180mm; weight approx 12.5 kg.
    Working Principle: Converts fixed frequency AC to variable frequency AC using PWM inverter technology with IGBT switches, regulating motor magnetic flux and torque.
    Advantages: High dynamic response; compact footprint; integrated safety and filtering; global certifications (CE, UL, cUL, RoHS).
    Applicable Industries: Conveyor systems, extrusion machinery, hoisting equipment, pump and fan control.
    Model Series: Lenze ESMD (SMD) Series / 9300 Vector Series.
    Installation Requirements: Cabinet wall-mounted; maintain minimum 100mm​ top/bottom clearance for airflow; ensure grounded enclosure; use shielded motor cables.
    Usage Precautions: Disable output before connecting/disconnecting motor; ensure ambient temperature does not exceed 50°C; verify motor insulation resistance before commissioning; configure motor parameters accurately to prevent overheating.
