HIMA F3501030 982200416

Product Name: HIMatrix F35 Compact Safety Controller
Product Introduction: The HIMA F3501030 (Order No. 982200416) is a compact, SIL 3 rated programmable safety controller from the HIMatrix F35 series, designed for small to medium-scale safety applications with integrated I/O and communication.
Category:
Description
Technical Specifications:
  • Model: F3501030
  • Order Number: 982200416​
  • Series: HIMatrix F35
  • Manufacturer: HIMA Paul Hildebrandt GmbH + Co KG
  • Processor: 32-bit ARM Cortex-M3​ (redundant dual-core)
  • Memory: 128MB Flash, 64MB RAM​
  • Digital Inputs: 24 channels​ (0…10V or dry contact configurable)
  • Digital Outputs: 8 channels​ (0.5A/1A ch1-7, 1A/2A ch8)
  • Analog Inputs: 8 channels​ (0…10V, 0…20mA​ with shunt)
  • Counter: 2 channels, 24-bit​ resolution (max 16,777,215)
  • Safety Grade: SIL 3​ (IEC 61508), PL e​ (ISO 13849), AK 6​
  • Supply Voltage: 24V DC​ (dual redundant 18-32V)
  • Power Consumption: 15W​ to 29W​ (load dependent)
  • Communication: 2 × Gigabit Ethernet, 2 × RS485​ (SafeEthernet, PROFIsafe, CIP Safety)
  • Operating Temp: -25°C​ to +70°C​ (some docs -20 to +60)
  • Protection: IP20​
  • Dimensions: Approx. 150mm​ × 100mm​ × 50mm​
  • Weight: Approx. 1.0kg​
Functional Features:
  • Voting Logic: Supports 1oo2, 2oo3​ internal evaluation.
  • Hot-Swap: Module-level online replacement supported in rack context.
  • Isolation: 2500V AC​ channel isolation on inputs.
  • Diagnostics: Line break/short, internal self-test, watchdog.
Performance Parameters:
  • Input Response: ≤5ms​ (fault-safe reaction)
  • Accuracy (AI): ±2%​ FS
  • Resolution: FS1000 / FS2000 configurable
Material Composition:
  • Housing: Metal chassis with polymer front connector cover.
  • PCB: Industrial grade with conformal coating.
Structural Features:
  • Mounting: HIMatrix cabinet slot or DIN rail adapter.
  • Indicators: Per-channel + system status LEDs.
Working Principle:
The dual ARM cores execute safety logic compiled in SILworX. Inputs are scanned via isolated multiplexers, evaluated against safety function blocks (ESD, BMS). Outputs are driven through diverse redundant drivers; discrepancy triggers safe state. Communication ports encapsulate safety data in black-channel protocols (SafeEthernet).
Advantages:
  • Compact footprint reduces panel space vs full rack systems.
  • SIL 3​ with integrated I/O eliminates external barrier needs in many cases.
  • Wide temp range (-25 to +70) suits outdoor skids.
Applicable Industries:
Machine Safety, Packaging lines, Burner Management (BMS), Small ESD packages, Railway crossings.
Model Series: HIMatrix F35 (F3501030, F3501100, etc.), Order No. 982200416.
Installation Requirements:
  • Mount on 35mm​ DIN rail or chassis slot with proper grounding.
  • Use 24V DC​ redundant PSU with controlled ripple (< 5%).
  • Separate signal and power wiring in cable ducts.
Usage Precautions:
  • Programming requires licensed SILworX​ software with safety library.
  • Do not mix 982200416​ order number with different firmware revisions without impact analysis.
  • Ensure analog input shunt resistors are correctly selected for 0…20mA​ range.
