ABB CI858K01 3BSE018135R1 Communication Module

• Transmission Rate: Supports high-speed data transmission rates up to 12 Mbps (PROFIBUS DP standard rate) and 1000 Mbps (Ethernet).
• Processor: Equipped with a 32-bit ARM processor with a clock speed of 1.2 GHz.
• Memory: Supports 256MB DDR3 memory for efficient data processing.
• FPGA Co-processor: Integrated FPGA co-processor for accelerating real-time control logic.
• Communication Interfaces: Features multiple communication interfaces such as Ethernet, serial ports, and CAN bus.
• Power Supply: Operates on 24V DC (±10%) with a typical power consumption of 12W and a maximum of 15W.
• Operating Temperature: -20°C to +60°C
• Storage Temperature: -40°C to +85°C
• Relative Humidity: 5% to 95% RH (non-condensing)
• Mechanical Dimensions: 120mm × 80mm × 45mm
• Installation: Standard DIN rail mounting or screw fixing
• Protection Class: IP20

Functional Characteristics

• High Reliability: Designed for industrial environments, ensuring stable and reliable operation under harsh conditions.
• Flexible Configuration: Offers flexible configuration options to adapt to different application needs and scenarios.
• Programmability: Supports programmable functions, allowing users to customize and write control logic as needed.
• Status Monitoring and Fault Diagnosis: Equipped with status monitoring and fault diagnosis functions for real-time monitoring of module working status and timely issue detection.
• Redundancy Design: Features dual-port communication for enhanced network stability and fault tolerance, avoiding single points of failure.
• High-Speed Data Processing: The ARM + FPGA architecture ensures millisecond-level real-time response capabilities.
• Wide Temperature Adaptability: Suitable for extreme industrial environments, reducing maintenance costs.

Application Scenarios

• Process Automation Systems: Utilized in distributed control systems (DCS) for sectors like chemicals, energy, and water treatment to integrate PROFIBUS-DP devices such as frequency converters and sensors into ABB 800xA DCS systems.
• Intelligent Manufacturing Equipment: Integrated into robot control, production line monitoring, and logistics automation systems for real-time data acquisition and transmission.
• Infrastructure Monitoring: Employed in building automation, rail transit, and power systems for real-time data collection and transmission.
• Factory Automation: Integrates PROFIBUS-DP devices like motor drives and valve controllers into AC 800M control systems on production lines.
• Equipment Upgrades: Facilitates the integration of existing PROFIBUS-DP devices into new ABB automation platforms, avoiding equipment replacement costs.
• Redundant Systems: Builds redundant communication links in critical applications to ensure continuous system operation.
