GE IS230SNTCH4A
Product Introduction:
The IS230SNTCH4A is a four-port serial communication module for GE Mark VIe control systems. It provides four independent RS-232/RS-485 serial ports for connecting multiple legacy devices, RTUs, modems, and third-party equipment simultaneously. Each port is independently configurable for protocol, baud rate, and data format.
GE IS230SNRTH2A
Product Type: Serial Communication Interface Module (RS-232/RS-485)
Product Introduction:
The IS230SNRTH2A is a dual-port serial communication module for GE Mark VIe systems. It provides RS-232 and RS-485 serial interfaces for connecting remote terminal units (RTUs), modems, and third-party serial devices. It supports Modbus RTU, DF1, and GE SRTP protocols with configurable baud rates up to 115200 bps.
GE IS230JPDMG1B
Product Type: JPEG Graphics Display Processor Module
Product Introduction:
The IS230JPDMG1B is a JPEG display processor module for GE Mark VIe control systems. It provides hardware-accelerated JPEG image decompression and drives VGA display output for HMI panels. It offloads all graphics rendering from the main CPU, enabling high-resolution displays with smooth animation, trending, and alarm graphics.
GE IS420ESWBH4A
Product Type: Managed Ethernet Switch Module (24-Port)
Product Introduction:
The IS420ESWBH4A is a 24-port Gigabit Ethernet managed switch for GE Mark VIe control systems. It is a compact alternative to the 48-port switch, designed for smaller turbine control networks or HMI/engineering station clusters. It provides full Layer 2 switching with VLAN, QoS, and RSTP redundancy.
GE IS420ESWDH1A
Product Type: Managed Ethernet Switch Module
Product Introduction:
The IS420ESWDH1A is a 48-port Gigabit Ethernet managed switch for GE Mark VIe systems. It is an earlier hardware revision of the IS420ESWDH5A with identical core functionality but older firmware architecture. It provides Layer 2 switching with VLAN, QoS, and redundant ring support for turbine control networks.
GE IS410JPDHG1A
Product Type: JPEG Graphics Display Processor Module
Product Introduction:
The IS410JPDHG1A is a JPEG graphics accelerator and display processor module for GE Mark VIe control systems. It offloads graphics rendering from the main CPU, enabling high-resolution HMI displays with smooth animation, trending, and alarm visualization. It supports JPEG image decompression in hardware and drives VGA/DVI display outputs.
GE IS230SNCIH2A
Product Type: Serial Communication Module (RS-232/RS-485)
Product Introduction:
The IS230SNCIH2A is a serial communication interface module for GE Mark VIe control systems. It provides RS-232 and RS-485 serial ports for connecting legacy devices, modems, RTUs, and third-party equipment that use serial protocols. The module supports Modbus RTU, DF1, and GE SRTP protocols.
GE IS230TNRLH3E
Product Type: Dual-Port Redundant Ethernet Communication Module
Product Introduction:
The IS230TNRLH3E is a dual-port redundant 10/100 Mbps Ethernet communication module designed for GE Mark VIe control systems requiring network redundancy. It provides two independent Ethernet ports that can operate in active/standby or load-sharing mode, ensuring continuous communication even if one port or network path fails.
GE IS230TNEAH5A
Product Introduction:
The IS230TNEAH5A is a single-port 10/100 Mbps Ethernet communication module for GE Mark VIe and Mark V control systems. It provides a dedicated Ethernet interface for connecting the control system to plant-level networks, HMI stations, and historian servers. The module uses RJ-45 connector and supports TCP/IP and UDP/IP protocols.
GE IS420ESWCH5A
Product Type: Managed Ethernet Switch Module for Industrial Control
Product Introduction:
The IS420ESWCH5A is a 24-port managed Gigabit Ethernet switch module for GE Mark VIe control systems. It serves as a compact alternative to the 48-port version, providing deterministic Ethernet switching for smaller turbine control networks. It supports 10/100/1000 Mbps auto-negotiation on all ports with full Layer 2 management capabilities.
GE IS420ESWDH5A
Product Type: Managed Ethernet Switch Module for Industrial Control
Product Introduction:
The IS420ESWDH5A is a 48-port managed Ethernet switch designed for the GE Mark VIe and Mark VI control systems. It provides high-bandwidth, deterministic communication for turbine and generator control networks. The module operates within the Mark VIe distributed control architecture, supporting both Gigabit Ethernet (1000 Mbps) and Fast Ethernet (100 Mbps) port speeds.
GE IS430SNUAH1A
Product Name: GE IS430SNUAH1A — Analog Input Module (Mark VI Series)
Product Overview:
The GE IS430SNUAH1A is a 16-channel analog input module for the GE Mark VIe distributed control system. It accepts multiple signal types including 4–20 mA, 0–10 V, thermocouple, and RTD inputs for process monitoring and control.
