GE IC200MDL241
Technical Specifications:
- Input Channels: 16 non-isolated inputs, divided into two groups of eight channels each.
- Voltage Ratings:
- Nominal operating voltage: 240 VAC.
- Operating voltage range: 0 to 264 VAC.
- On-state voltage range: 155 VAC to 264 VAC.
- Off-state voltage range: 0 to 40 VAC.
- Current Consumption:
- Maximum backplane current consumption: 110 mA at 110.0 V.
- Maximum operating current: 5.0 mA at 110.0 V from the backplane.
GE IC200MDD844
Technical Specifications:
- I/O Points: Provides a total of 32 I/O points, divided into 1 group of 16 outputs and 2 groups of 8 inputs each.
- Output Types: Supports two types of outputs - positive logic and sourcing, enabling the module to supply DC voltage to loads.
- Input Types: The 32 input points are of positive logic type, allowing them to draw current from connected devices and return it to the common wire.
- Input Voltage Range: 0 to 30 volts.
- Output Voltage Range: 10.2 to 30 volts.
GE IC200GBI001
Technical Specifications:
- I/O Capacity: Supports up to 64 I/O modules (8 modules per rack, with a maximum of 8 racks).
- Memory: 1024 discrete input points, 1024 discrete output points, 128 bytes of analog input memory, and 128 bytes of analog output memory.
- Transmission Speed: Supports up to 153.6 kbaud for extended network configurations, with standard speeds of 153.6 kbaud, 76.8 kbaud, and 38.4 kbaud.
- Bus Connections: Dual Genius bus terminals (upper terminal for primary connection, lower terminal for redundancy).
- Power Consumption: 250 mA at 4VDC and 10 mA at 3.3VDC.
GE IC200EBI001-NJ
Technical Specifications:
- Bus Connections: Two Genius bus connections (upper terminals for primary connection, lower terminals for redundancy).
- Transmission Speed: Supports up to 38.4 Kbaud for standard configurations and up to 153.6 Kbaud for extended network configurations.
- I/O Capacity: Each rack can accommodate up to eight I/O modules, with support for up to eight racks (64 I/O modules in total).
- Memory: 1024 points of discrete input memory, 1024 bytes of discrete output memory, 128 bytes of analog input memory, and 128 bytes of analog output memory.
GE IC200CPUE05
Technical Specifications:
- Processor: High-performance 32-bit processor.
- Memory: 64KB user-configurable memory for program storage.
- I/O Capacity: Supports up to 64 modules, expandable to 2048 I/O points.
- Communication Interfaces:
- RS-232 for local programming and debugging.
- RS-485 for Modbus RTU master/slave communication.
- Ethernet (10Mbps, half-duplex or full-duplex) for remote monitoring and data exchange.
GE IC200CHS022
Technical Specifications:
- Slots: 2 slots for installing IC200 series modules (e.g., CPU, power supply, or I/O modules).
- Mounting: DIN-rail mounting (TS-35/7.5 or TS-35/15 standard).
- Backplane: Built-in electrical backplane for automatic power and data signal connections between modules, eliminating the need for additional jumpers.
- Terminals: Pluggable screw-type terminal blocks for easy and quick wiring and maintenance. Some models support pre-wired terminals.
- Dimensions: 16.5 x 6.5 x 7 cm.
- Weight: 0.24 kg.
GE IC200CHS002K
Technical Specifications:
- Terminal Configuration: 36 IEC box-type terminals arranged in two groups (A1-A18 and B1-B18).
- Voltage Range: Supports up to 0-264 VAC, with a transient voltage tolerance of up to 300 VAC.
- Current Capacity: Each terminal rated for 2 Amps, with 8 Amps per power/ground terminal.
- Wire Compatibility: Accepts solid or stranded copper wires ranging from AWG #14 to AWG #22.
- Installation: Designed for horizontal mounting only, with a minimum enclosure depth requirement of 70 mm.
- Backplane Communication: Provides communication and power for hosted I/O modules through a carrier mating connector.
GE IC200ALG331-KD
Technical Specifications:
Output Channels: 4 single-ended analog output channels, each with independent isolation.
Resolution: 16-bit, ensuring high-precision analog output.
Output Signal Types: Supports both voltage and current output signals, including ±10 VDC and 4-20 mA (requires an external 250 Ω resistor for current-to-voltage conversion).
Accuracy: Maximum accuracy of ±0.1% of full scale, ensuring reliable data acquisition.
Update Rate: Each channel has a maximum update rate of 7 milliseconds, enabling fast response to signal changes.
GE IC200ALG331-KD
Technical Specifications:
- Output Channels: 4 single-ended analog output channels, each with independent isolation.
- Resolution: 16-bit, ensuring high-precision analog-to-digital conversion.
- Output Signal Types: Supports both voltage and current output signals, including ±10 VDC and 4-20 mA (requires an external 250 Ω resistor for current-to-voltage conversion).
- Accuracy: Maximum accuracy of ±0.1% of full scale, ensuring reliable data acquisition.
- Update Rate: Each channel has a maximum update rate of 7 milliseconds, enabling fast response to signal changes.
GE IC200ALG326H
Technical Specifications:
- Input Channels: 16 single-ended or 8 differential analog input channels, providing flexibility in sensor connection.
- Resolution: 12-bit resolution, ensuring high-precision analog-to-digital conversion.
- Input Signal Types: Supports multiple standard signal types, including ±10 V, 0-10 V, 0-5 V, 0-20 mA, and 4-20 mA (requires an external 250 Ω resistor for current-to-voltage conversion).
- Accuracy: Typical accuracy of ±0.1% of full scale, ensuring reliable data acquisition.
- Sampling Rate: Approximately 200 microseconds per channel, enabling fast response to signal changes.
GE IC200ALG325
Technical Specifications:
- Output Channels: 8 single-ended analog output channels.
- Resolution: 13-bit, ensuring high-precision analog output.
- Output Signal Types: Supports both bipolar and unipolar voltage outputs, including -10 VDC to +10 VDC (bipolar) and 0 VDC to +10 VDC (unipolar).
- Output Current: Each channel can provide a maximum current of 50 mA at 5 VDC.
- Isolation: Provides isolation between user inputs and logic/frame ground, enhancing system reliability and safety.
- Update Rate: 7.5 milliseconds per channel, meeting real-time control requirements.
GE IC200ALG264H
Technical Specifications:
- Input Channels: 15 single-ended analog input channels.
- Resolution: 15-bit digital resolution, ensuring high-precision measurement.
- Input Signal Types: Supports both 4-20 mA and 0-20 mA current signals, covering common industrial sensor signal ranges.
- Analog Resolution: 0.5 μA per count for the 4-20 mA range; 0.625 μA per count for the 0-20 mA range.
- Input Accuracy: Typical value of ±0.5% at an ambient temperature of 0-3°C; maximum full-scale value of ±0.25% at 0-3°C and ±0.6% at 10-0°C.
