ABB

• Input Voltage: 24V DC
• Output Voltage: 3.3V, 5V, 12V
• Rated Power: 50W
• Screen Size: 10.1 inches
• Resolution: 1024 x 768 pixels
• Communication Ports: Ethernet, RS485, USB
• Operating Temperature: -20°C to 70°C
• Storage Temperature: -40°C to 85°C
• Humidity: 5% to 95% (non - condensing)
• Dimensions: 160 mm x 100 mm x 25 mm
• Weight: 500 g

Technical Specifications

• Input Signal Types:
  • Current signals: 4-20 mA DC (2-wire/4-wire transmitter compatible)
  • Voltage signals: 0-10 V DC, ±10 V DC (bipolar), 0-5 V DC
  • Temperature signals (via external transmitters): Supports input from RTDs (Pt100, Pt1000) and thermocouples (Type J, K, T, E) when paired with signal conditioners
• Number of Input Channels: 8 independent analog input channels (channel-to-channel isolation)
• Input Resolution: 16-bit ADC (Analog-to-Digital Converter) for high-fidelity signal conversion
• Measurement Accuracy:
  • For 4-20 mA DC: ±0.1% of full scale (FS) at 25°C (ambient temperature)
  • For 0-10 V DC/±10 V DC: ±0.1% of full scale (FS) at 25°C
  • For 0-5 V DC: ±0.15% of full scale (FS) at 25°C
• Isolation:
  • Channel-to-channel isolation: 500 V AC (rms) for 1 minute (prevents cross-channel interference)
  • Module-to-backplane isolation: 1500 V AC (rms) for 1 minute (protects the control system backplane from field voltage spikes)

• Communication Protocols: Supports various protocols such as Modbus RTU, Profibus DP, Ethernet, and Ethernet/IP for versatile connectivity.
• Interface Types: Equipped with RS-232, RS-485, and Ethernet interfaces to meet different communication requirements.
• Power Supply: Requires a stable 24V DC power supply for reliable operation.
• Operating Temperature: Withstands temperatures ranging from -20°C to 70°C, making it suitable for harsh industrial conditions.
• Dimensions: Compact design for standard DIN rail mounting, facilitating easy installation in control cabinets.
• Weight: Lightweight construction for convenient handling and integration.
• Protection Rating: Features an IP20 protection rating to prevent dust and moisture ingress.

Technical Specifications

• Output Signal Type: Discrete digital outputs (voltage-driven, solid-state switching)
• Number of Output Channels: 16 independent digital output channels (group-isolated configuration)
• Output Voltage Range:
  • Nominal voltage: 24 V DC (standard industrial low-voltage supply)
  • Operating voltage tolerance: 19.2 V DC to 30 V DC (accommodates field power fluctuations)
• Output Current Capacity:
  • Maximum continuous current per channel: 2 A (supports high-load devices like small motors or solenoids)
  • Maximum inrush current per channel: 5 A (peak, for 100 ms, to handle startup surges of inductive loads)
  • Maximum total current per module: 16 A (sum of all active channels)

• Processor: Equipped with a low-power Pentium M/Celeron M processor for efficient computing.
• Memory: Supports up to 1GB of DDR SDRAM for smooth operation.
• BIOS: Features a 2/4MB Phoenix flash BIOS with plug-and-play functionality.
• Expansion Slots: Provides one PCI expansion slot for additional functionality.
• I/O Interfaces: Includes IDE, USB, PS/2, and infrared interfaces for diverse connectivity options.
• Network Interface: Equipped with an RTL8100C 10/100M Ethernet controller for seamless network integration.

• Communication Protocols: Supports Modbus RTU, Profibus DP, Ethernet, and other industrial protocols for versatile connectivity.
• Interface Types: Equipped with RS-232, RS-485, and Ethernet interfaces to meet different communication requirements.
• Power Supply: Requires a stable 24V DC power supply for operation.
• Operating Temperature: Functions reliably within a temperature range of -20°C to 70°C, adapting to harsh industrial environments.
• Dimensions: Compact design for standard DIN rail mounting, facilitating easy integration into control cabinets.
• Weight: Lightweight construction for convenient installation and handling.
• Protection Rating: Features an IP20 protection rating to prevent dust and moisture ingress.
