ALSTOM N897164610L Control and Protection Module
echnical Specifications:
- Voltage Rating: Supports a wide range of operating voltages, typically compatible with medium-voltage (MV) and high-voltage (HV) systems.
- Current Rating: Designed to handle high current levels, ensuring robust performance in demanding industrial environments.
- Communication Protocols: Supports standard industrial communication protocols such as Modbus, IEC 61850, and Profibus for seamless integration with SCADA systems and other control devices.
- Input/Output (I/O) Channels: Equipped with multiple digital and analog I/O channels for connecting sensors, actuators, and other field devices.
- Protection Functions: Includes overcurrent, overvoltage, undervoltage, differential, and distance protection capabilities.
- Environmental Resistance: Operates reliably in temperatures ranging from -20°C to +70°C and is resistant to humidity, dust, and vibration.
- Physical Dimensions: Compact and rugged design suitable for installation in control panels or outdoor enclosures.
ALSTOM N895313512X Industrial Control Module
Technical Specifications:
- Input/Output (I/O) Configuration:
- Supports up to 62 analog/digital I/O channels (standard configuration).
- Expandable to 1,024 I/O channels via local or remote extension modules (up to 1,000 m distance).
- Includes 30 digital inputs (2 for axis encoders), 2 analog inputs, 28 digital outputs, and 2 high-speed digital outputs.
- Communication Interfaces:
- Ethernet and serial ports for seamless integration with PLCs, sensors, and control systems.
- Supports Profibus, Foundation FieldBus, and other industrial protocols.
- Power Requirements:
- Operating voltage: 220 V AC/DC.
- Power consumption: 250 W.
ALSTOM LE109A-1 Power System Control Module
Technical Specifications:
- Input/Output Channels: Equipped with multiple digital and analog I/O channels for connecting sensors, actuators, and other control devices.
- Digital I/O: 4 channels, configurable as inputs or outputs (e.g., incremental encoders, SSI transmitters).
- Voltage Supply: 24 V DC (18–36 V DC range), compliant with SELV standards (DIN EN 60950-1).
- Current Consumption: 0.3 A (idle); 2 A (all digital outputs active).
- Sensor Interfaces:
- Incremental Encoder: Supports standard, pulse train, and frequency measurement modes (max. 8 MHz pulse frequency).
- SSI Transmitter: Configurable as master or slave, with gray/binary code data formats (8–32 bits) and transmission frequencies of 78 kHz–5 MHz.
- Wire Fault Monitoring: Detects input errors and protects against 24 V faults.
ALSTOM EP3-E-4-A Controller Module
Technical Specifications:
- Input Voltage: AC 220V/380V
- Control Interface: RS485, Modbus protocols
- Operating Temperature: -20°C to +55°C
- Communication: Supports multi-protocol compatibility and flexible configuration
- Diagnostic Features: Self-diagnosis and remote monitoring capabilities
- Component Quality: Industrial-grade hardware for durability
ALSTOM AS111-1 Analog Output Module
Technical Specifications:
- Output Channels: 8 channels
- Output Signal Types:
- Current: 0–20 mA or 4–20 mA
- Voltage: 0–10 V
- Supply Voltage: 24 V DC (operating range: 19.2–30 V)
- Signal Accuracy: Industrial-grade precision, suitable for precise process control
- Isolation: Analog and digital circuits are isolated to enhance system anti-interference capabilities
- Feedback Mechanism: Built-in loop self-check function for output monitoring and calibration
- Dimensions: Approximately 26.5 × 2.6 × 26.5 cm
- Weight: Approximately 0.53 kg
