Bently Nevada 3304/00-01-05
Product Introduction
The 330400-01-05 is a rugged, case-isolated piezoelectric accelerometer designed for continuous casing vibration monitoring on critical rotating and reciprocating machinery. It delivers a standard 100 mV/g sensitivity over a 50 g peak range and meets API 670 requirements for accelerometer performance. The hermetically sealed 316 L stainless-steel housing and IP68 rating ensure long-term reliability in extreme humidity, dust and offshore salt-laden atmospheres, while the 5 m double-shielded armored cable provides electrical noise immunity and mechanical protection from the sensor all the way to the junction box.
Technical Specifications
-
Sensing Technology: Compression-type piezo-ceramic element, helium sealed
-
Sensitivity: 10.2 mV/m/s² (100 mV/g) ±5 %
-
Amplitude Range: ±490 m/s² (±50 g) peak
-
Frequency Response: 0.5 Hz – 5 kHz ±3 dB; 10 Hz – 15 kHz ±10 %
-
Mounted Resonant Frequency: ≥30 kHz
-
Transverse Sensitivity: ≤5 % of axial
-
Broad-band Noise Floor: 0.039 m/s² (0.004 g) rms (10 Hz – 15 kHz)
Bently Nevada 330195-02-12-90-05
Product Introduction
The 330195-02-12-90-05 is a rugged, high-precision eddy-current proximity probe from the 3300 XL series, purpose-built for reverse-mount installations where frontal access is impossible. The 90 cm armored stainless-steel jacket protects the cable from abrasion, chemicals, and moisture while the probe delivers 7.87 V/mm (200 mV/mil) sensitivity across the full –55 °C to +218 °C temperature range. When paired with any 3300 XL extension cable and Proximitor sensor, it forms a complete 0.5-metre system for continuous vibration and axial-position monitoring on critical rotating machinery.
Technical Specifications
-
Probe Tip Diameter: 8 mm
-
Mounting Style: Reverse mount (rear-access)
-
Thread Specification: 3/8-24 UNF
-
Total Probe Length: 0.5 metre (1.6 ft)
-
Armor Option: 90 cm stainless-steel armor over cable
-
Connector: Miniature gold-plated ClickLoc coaxial
-
Temperature Range: –55 °C to +218 °C (–67 °F to +424 °F)
Bently Nevada 330195-02-12-05-05
Product Introduction
The 330195-02-12-05-05 is a compact, high-precision eddy-current proximity probe from the 3300 XL series, engineered for reverse-mount installations where frontal access is restricted. It delivers 7.87 V/mm (200 mV/mil) sensitivity and is designed to operate seamlessly with 3300 XL extension cables and Proximitor sensors to form a complete 0.5-metre system for continuous vibration and position monitoring of rotating machinery.
Technical Specifications
-
Probe Tip Diameter: 8 mm
-
Mounting Style: Reverse mount (rear-access)
-
Thread Specification: 3/8-24 UNF
-
Total Probe Length: 0.5 metre (1.6 ft)
-
Connector: Miniature ClickLoc coaxial, gold-plated
-
Temperature Range: –55 °C to +218 °C (–67 °F to +424 °F)
Bently Nevada 330192-00-12-90-CN
Product Introduction
The 330192-00-12-90-CN is a rugged, high-performance eddy-current proximity probe from the 3300 XL series, engineered for continuous vibration and position monitoring of rotating machinery. It operates across an extended temperature range and is fully armored for protection in harsh industrial environments. The probe integrates seamlessly with Bently Nevada 3300 XL Proximitor sensors and extension cables to form a complete 5-metre system delivering 7.87 V/mm (200 mV/mil) sensitivity.
Technical Specifications
-
Probe Tip Diameter: 8 mm
-
Thread Style: 3/8-24 UNF
-
Case Length: 12 mm (shorty housing)
-
Total Probe Length: 90 mm
-
Armoring: Armored stainless-steel outer sheath
-
Temperature Range: –55 °C to +218 °C (–67 °F to +424 °F)
-
Sensitivity: 7.87 V/mm (200 mV/mil) at 2 kHz
-
Frequency Response: 0 to 10 kHz (–3 dB)
-
Power Supply: –24 Vdc (supplied by Proximitor)
-
Output: Voltage-proportional to gap between probe tip and conductive target
-
System Length: 5 metres when combined with recommended extension cable and Proximitor
-
Agency Approvals: ATEX, IECEx, CSA, CE, CNEx (China)
Bently Nevada 330180-X0-05 Proximitor Sensor
Technical Specifications
-
Part Number: 330180-X0-05
-
System Length: 1.0 m (3.3 ft)
-
Power Supply: −17.5 Vdc to −26 Vdc (max 12 mA)
-
Output: −2 Vdc to −18 Vdc linear voltage, proportional to gap
-
Linear Range: 2 mm (80 mil) starting 0.25 mm (10 mil) from target
-
Sensitivity: 7.87 V/mm (200 mV/mil)
-
Linearity: ±0.5 % of full scale
-
Frequency Response: 0 Hz to 10 kHz
-
Operating Temperature: −51 °C to +100 °C
-
Storage Temperature: −51 °C to +105 °C
-
Mounting: Panel mount (4-hole) or DIN-rail; electrically insulated base eliminates separate isolator plate
-
Connectors: Gold-plated, corrosion-resistant ClickLoc coaxial, finger-tight with audible latch
-
Housing: A308 aluminum with stainless-steel hardware
-
Weight: 246 g
-
Protection: IP67 when installed
-
Agency Approvals: ATEX, IECEx, CSA, NEPSI (suffix 05)
Bently Nevada 330190-040-00-CN Extension Cable
Technical Specifications
-
Part Number: 330190-040-00-CN
-
Cable Length: 4.0 m (13.1 ft)
-
Characteristic Impedance: 75 Ω ±2 %
-
Conductor: Silver-plated copper, triaxial construction
-
Insulation/Jacket: Fluorinated ethylene-propylene (FEP), −51 °C to +177 °C
-
Outer Diameter: 3.8 mm (0.15 in)
-
Minimum Bend Radius: 25 mm (1 in)
-
Weight: 0.35 kg (0.77 lb)
-
Connector: Miniature coaxial, ClickLoc, gold-plated, IP67 when mated
-
Pull Strength: 330 N (75 lbf) guaranteed at connector interface
-
Capacitance: 69.9 pF/m (21.3 pF/ft) typical
-
Center-Conductor Resistance: 0.88 Ω ±0.13 Ω (4 m length)
-
Power Supply Range: −17.5 Vdc to −26 Vdc, 12 mA max
-
Agency Option: CN – China NEPSI Ex ia IIC T4 Ga approval
Bently Nevada 330180-91-CN Proximitor Sensor
Technical Specifications
-
Part Number: 330180-91-CN
-
System Length: 9 m (29.5 ft)
-
Power Supply: −17.5 Vdc to −26 Vdc (non-isolated); −23 Vdc to −26 Vdc with barriers
-
Current Consumption: ≤12 mA
-
Output: −2 Vdc to −18 Vdc linear voltage, proportional to gap
-
Linear Range: 2 mm (80 mil) starting 0.25 mm (10 mil) from target
-
Sensitivity: 7.87 V/mm (200 mV/mil)
-
Linearity: ±1 % of full scale
-
Frequency Response: 0 Hz to 10 kHz
-
Operating Temperature: −51 °C to +100 °C
-
Storage Temperature: −51 °C to +105 °C
-
Mounting: High-density DIN-rail or 4-hole panel; electrically insulated base eliminates separate isolator plate
-
Connectors: Gold-plated, corrosion-resistant ClickLoc coaxial, finger-tight with audible latch
-
Housing: A308 aluminum with stainless-steel hardware
-
Weight: 0.7 kg
-
Protection: IP67 when installed
-
Agency Approvals: China NEPSI Ex ia IIC T4 Ga, GB/T compliance
Bently Nevada 330180-91-05 Proximitor Sensor
Technical Specifications
-
Part Number: 330180-91-05
-
System Length: 9 m (29.5 ft)
-
Power Supply: −17.5 Vdc to −26 Vdc (non-isolated); −23 Vdc to −26 Vdc with barriers
-
Current Consumption: ≤12 mA
-
Output: −2 Vdc to −18 Vdc linear voltage, proportional to gap
-
Linear Range: 2 mm (80 mil) starting 0.25 mm (10 mil) from target
-
Sensitivity: 7.87 V/mm (200 mV/mil)
-
Linearity: ±0.025 mm (±1 mil)
-
Frequency Response: 0 Hz to 10 kHz
-
Operating Temperature: −52 °C to +85 °C
-
Storage Temperature: −52 °C to +100 °C
-
Mounting: High-density DIN-rail or 4-hole panel; electrically insulated base eliminates separate isolator plate
-
Connectors: Gold-plated, corrosion-resistant ClickLoc coaxial, finger-tight with audible latch
-
Housing: Die-cast aluminum with stainless-steel hardware
-
Weight: 246 g
-
Protection: IP67 when installed
-
Agency Approvals: ATEX, IECEx, CSA, NEPSI (integrated in 05 option)
Bently Nevada 330180-91-00 Proximitor Sensor
Technical Specifications
-
Part Number: 330180-91-00
-
System Length: 9 m (29.5 ft)
-
Power Supply: −17.5 Vdc to −26 Vdc (non-isolated); −23 Vdc to −26 Vdc when used with barriers
-
Current Consumption: ≤12 mA
-
Output: −2 Vdc to −18 Vdc linear voltage, proportional to gap
-
Linear Range: 2 mm (80 mil) starting 0.25 mm (10 mil) from target
-
Sensitivity: 7.87 V/mm (200 mV/mil)
-
Linearity: ±0.025 mm (±1 mil)
-
Frequency Response: 0 Hz to 10 kHz
-
Operating Temperature: −52 °C to +100 °C (−62 °F to +212 °F)
-
Storage Temperature: −52 °C to +105 °C (−62 °F to +221 °F)
-
Mounting: High-density DIN-rail or traditional 4-hole panel; electrically insulated base eliminates separate isolator plate
-
Connectors: Gold-plated, corrosion-resistant ClickLoc coaxial, finger-tight with audible latch
-
Housing: A308 aluminum with stainless steel hardware
-
Weight: 246 g
-
Protection: IP67 when installed
-
Agency Option: 00 – no special certifications
Bently Nevada 330180-90-05 Proximitor Sensor
Technical Specifications
-
Part Number: 330180-90-05
-
System Length: 9 m (29.5 ft)
-
Power Supply: −17.5 Vdc to −26 Vdc (non-isolated); −23 Vdc to −26 Vdc (with safety barrier)
-
Maximum Current: 12 mA
-
Output Signal: −0.8 Vdc to −22 Vdc linear voltage
-
Linear Range: 2 mm (80 mil) beginning 0.25 mm (10 mil) from target
-
Sensitivity: 7.87 V/mm (200 mV/mil)
-
Linearity: ±0.5 % full scale
-
Frequency Response: 0 Hz to 10 kHz
-
Temperature Range: −40 °C to +85 °C (operating); storage to +100 °C
-
Mounting: DIN-rail or 4-hole panel; electrically insulated base eliminates separate isolator plate
-
Connectors: Gold-plated, corrosion-resistant ClickLoc coaxial, finger-tight with audible latch
-
Dimensions: 100 mm × 50 mm × 60 mm
-
Weight: 246 g
-
Protection: IP67
-
Agency Approvals: API 670 4th Edition, CE, UL, CSA, ATEX Zone 2, IECEx, NEPSI
Bently Nevada 330180-51-CN Proximitor Sensor
Technical Specifications
-
Part Number: 330180-51-CN
-
Sensor System: 3300 XL 8 mm
-
Power Supply: −17.5 Vdc to −26 Vdc (non-isolated); −23 Vdc to −26 Vdc (with safety barrier)
-
Maximum Current: 12 mA
-
Output Signal: −2 Vdc to −18 Vdc proportional to gap
-
Linear Range: 2 mm (80 mil) beginning 0.25 mm (10 mil) from target
-
Sensitivity: 7.87 V/mm (200 mV/mil)
-
Linearity: ±0.025 mm (±1 mil)
-
Frequency Response: 0 Hz to 10 kHz
-
Temperature Range: −35 °C to +85 °C operating; −35 °C to +100 °C storage
-
Mounting: High-density DIN-rail or traditional panel; electrically insulated base eliminates separate insulator
-
Connectors: Gold-plated, corrosion-resistant ClickLoc coaxial, finger-tight with audible latch
-
Agency Option: CN – China NEPSI Ex ia IIC T4 Ga approval
Bently Nevada 330180-51-05 Proximitor Sensor
Technical Specifications
-
Part Number: 330180-51-05
-
Sensor System: 3300 XL 8 mm
-
Power Supply: −17.5 Vdc to −26 Vdc (non-isolated); −23 Vdc to −26 Vdc (with safety barrier)
-
Maximum Current: 12 mA
-
Output Signal: −2 Vdc to −18 Vdc proportional to gap
-
Linear Range: 2 mm (80 mil) beginning 0.25 mm (10 mil) from target
-
Sensitivity: 7.87 V/mm (200 mV/mil)
-
Linearity: ±0.025 mm (±1 mil)
-
Frequency Response: 0 Hz to 10 kHz
-
Temperature Range: −35 °C to +85 °C operating; −35 °C to +100 °C storage
-
Mounting: High-density DIN-rail or traditional panel; electrically insulated base eliminates separate insulator
-
Connectors: Gold-plated, corrosion-resistant ClickLoc coaxial, finger-tight with audible latch
-
Agency Option: 05 – CSA, ATEX, IECEx, NEPSI multiple approvals
