GE IC693MDL740

Product Introduction

The IC693MDL740 is a 16-point discrete output module tailored for the GE Fanuc Series 90-30 PLC system, designed to drive 12/24VDC loads via positive (sourcing) logic. It features two independent groups of 8 output points with separate common terminals, delivering 0.5 A per channel and 2 A per group common, supporting inrush currents up to 4.78 A for 10 ms to handle inductive loads like relays and solenoids. The module provides 1500 VDC isolation between field and logic sides and 500 VAC between groups, with individual green LEDs for each output point to enable real-time status monitoring. It uses a 20-screw terminal block for secure wiring, draws 110 mA from the 5 VDC backplane, and fits any I/O slot of 5-slot or 10-slot Series 90-30 baseplates, serving as a reliable solution for industrial load control applications.
Read more
Quick view

GE IC693MDL742

Product Overview

The IC693MDL742 is a single‑slot 16‑channel discrete output module from GE Fanuc (now part of Emerson Automation) for the Series 90‑30 PLC platform, featuring two 8‑channel groups with individual commons and Electronic Short Circuit Protection (ESCP). It uses positive logic (sourcing) to drive 12/24VDC loads, with 1500V field‑to‑logic and 500V group‑to‑group isolation, plus 1A per‑channel and 3–4A per‑group current ratings (temperature‑dependent). The module delivers 5.2A inrush for 10 ms, 1.2V max voltage drop, 1 mA max off‑state leakage, and 2 ms max on/off response times, with 130 mA max 5V backplane draw. It integrates with all Series 90‑30 CPUs, baseplates, and power supplies, serving as a protected, high‑density output interface for industrial solenoids, indicators, and motor starters.
Read more
Quick view

GE IC693MDL752 32-Point Negative Logic Digital Output Module

Product Overview The GE IC693MDL752 is a 32-point discrete output module designed for the GE Fanuc Series 90-30 Programmable Logic Controller (PLC) platform. It translates the PLC's internal logic commands into physical sinking (negative logic) control signals to drive external devices. This module features dual-mode operation, supporting both 5V TTL and 12/24VDC loads, with outputs arranged in four isolated groups of eight points each. It is compatible with any standard I/O slot in a 5-slot or 10-slot Series 90-30 baseplate.
Read more
Quick view

GE IC693MDL753

Product Introduction

The IC693MDL753 is a 32-point discrete output module dedicated to the GE Fanuc Series 90-30 PLC system, designed to drive 12/24VDC loads through positive (sourcing) logic. It has 32 output points divided into four isolated groups of eight, each with an independent common terminal that can bear up to 3A current per pin. The module can provide 0.5A current per channel and 4A current per group, supporting an inrush current of 5.4A for 10ms to meet the operation of inductive loads. It is equipped with optocouplers that provide 1500VDC isolation between the field side and the logic side to ensure the safety and stability of the system. Each output point is equipped with an individual green LED indicator for real-time monitoring, and it is installed with a 26-screw removable terminal block for easy wiring. It draws 260mA from the 5VDC backplane and can be inserted into any I/O slot of the Series 90-30 baseplate, making it an ideal choice for high-density and high-reliability load control applications.
Read more
Quick view

GE IC693MDL753K

Product Overview

The IC693MDL753K is a 32‑channel discrete output module from GE Fanuc (now part of Emerson Automation) for the Series 90‑30 PLC platform, offering 0.5A per‑channel transistor outputs in four isolated groups of eight channels each, with independent commons for flexible field wiring. It employs 1500VAC field‑to‑logic optical isolation to shield against electrical noise and transients, supports 10.2–28.8VDC output voltage, and delivers 5.4A inrush current for 10 ms to handle inductive loads like solenoids and small motors. The module has a 260 mA 5V backplane power draw, 0.3V max on‑state voltage drop, and 1.1 mA max off‑state leakage current, ensuring efficient and reliable operation in industrial environments. It integrates seamlessly with Series 90‑30 baseplates, power supplies, and CPUs, serving as a high‑density, isolated interface for controlling multiple DC loads in automation systems.
Read more
Quick view

GE IC693MDL930 4 Amp Isolated Relay Output Module

Product Introduction The IC693MDL930 is a discrete output module manufactured by GE Fanuc (now Emerson Automation Solutions) for the Series 90-30 Programmable Logic Controller (PLC) system. It provides 8 normally-open (Form A) relay circuits for controlling user-supplied output loads. Each output point is individually isolated from all other points, and each features a separate common power output terminal.
Read more
Quick view

GE IC693MDL940

Product Introduction

The IC693MDL940 is a 16-point normally-open (NO) relay output module designed for the GE Fanuc Series 90-30 PLC system, engineered to switch AC/DC loads with 2 A per channel and 4 A per group common. It features four isolated groups of 4 output points each, with independent common terminals, supporting 5-30 VDC and 5-250 VAC (50/60 Hz) field voltages to control devices like motor starters, solenoids, and indicators. The module provides 1500 VDC isolation between field and logic sides and 500 VAC between groups, with individual green LEDs for each output point for real-time status monitoring. It uses a 20-pin removable terminal block, draws 7 mA from the 5 VDC backplane and 135 mA from the 24 VDC backplane (all outputs on), and fits any I/O slot of Series 90-30 baseplates, serving as a robust solution for switching heavy industrial loads.
Read more
Quick view

GE IC693MDL940H

Product Overview

The IC693MDL940H is a single‑slot 16‑channel relay output module from GE Fanuc (now Emerson Automation) for the Series 90‑30 PLC platform, configured as 4 groups of 4 channels with independent commons. It provides 1500VAC field‑to‑logic and 500V group‑to‑group isolation, handling 5–30VDC/5–250VAC loads at 2A per channel. The module draws 7 mA from the 5V backplane and 135 mA from the 24V backplane (all outputs ON), with green LEDs per channel for output status. It integrates with all Series 90‑30 CPUs, baseplates, and power supplies, serving as a robust, isolated interface for industrial motor starters, solenoids, and indicators.
Read more
Quick view

GE IC693MDL940L

Product Introduction

The IC693MDL940L is a 16-point normally-open (NO) relay output module belonging to the GE Fanuc Series 90-30 PLC system, tailored to switch both AC and DC loads with 2A per channel and 4A per group common. It is structured into four isolated groups of four output points each, each group having an independent common terminal. The module supports 5-30VDC and 5-250VAC (50/60Hz) field voltages, and provides 1500VDC isolation between the field and logic sides, as well as 500VAC isolation between groups. It is fitted with individual green LED indicators for each output point, uses a 20-pin removable terminal block, and draws 7mA from the 5VDC backplane and 135mA from the 24VDC backplane when all outputs are on. It can be installed in any I/O slot of Series 90-30 baseplates, providing a reliable solution for controlling heavy industrial loads in various automation applications.
Read more
Quick view

GE IC693MDR390C

Product Overview

The IC693MDR390C is a single‑slot mixed I/O module from GE Fanuc (Emerson Automation) for the Series 90‑30 PLC platform, integrating 8 channels of 24VDC discrete input (sinking/sourcing) and 8 channels of normally‑open relay output (2 groups × 4 channels, independent commons). It features 1500VAC field‑to‑logic optical isolation and 500VAC group‑to‑group isolation to block noise and transients, supporting 15–32VDC input voltage and 5–30VDC/5–250VAC output voltage. The module delivers 2A max per output channel and 4A max per group common, with 70 mA 24V relay supply and 80 mA 5V backplane power draw. It offers 7 ms typical input response and ≤15 ms output response, with channel‑level LEDs for input/output status, serving as a compact, integrated interface for combined sensing and actuation in industrial automation.
Read more
Quick view

GE IC693PBM200 PROFIBUS-DP Master Module

The IC693PBM200 is a PROFIBUS-DP Master communication module designed for the GE Fanuc Series 90-30 PLC system. It functions as the primary interface between the PLC and a PROFIBUS-DP fieldbus network, enabling high-speed data exchange with distributed field devices, remote I/O stations, drives, and other automation equipment. The module scans all configured slave devices, sending outputs and reading inputs, with support for up to 125 DP slaves and 244 bytes of input plus 244 bytes of output data per slave.
Read more
Quick view

GE IC693PCM311 Programmable Coprocessor Module

The GE IC693PCM311 is a high-performance Programmable Coprocessor Module (PCM) for the GE Fanuc Series 90-30 PLC platform . It is designed to expand the capabilities of the host PLC by executing complex control algorithms, data processing, and serial communications that would be difficult or impossible for the PLC’s CPU to handle alone. Supporting MegaBasic and C programming languages, the module provides a powerful, flexible platform for custom automation solutions . It features two configurable serial ports accessible via a single front-panel connector, enabling simultaneous communication with a wide variety of external devices .
Read more
