HIMA F7553 984755302 Programmable Bus Coupling Module
Technical Specifications
- Compatibility: Designed for HIMA HIMatrix and PES H51q systems.
- Safety Integrity Level (SIL): Typically supports SIL 3 systems (module self-diagnostics).
- Power Supply: 5 VDC or 24 VDC.
- Power Consumption: 600 mA (typical at 5 VDC); 750 mA (typical at 24 VDC).
- Self-Diagnostic Functions: Automatic testing and safety-related watchdog signal monitoring.
- Indicators: LED indicators for watchdog signal (WD) and I/O module access (SEL).
- Physical Dimensions: 4 TE width (approximately 85 mm wide x 35 mm high x 125 mm deep).
- Weight: Approximately 0.14 kg to 0.2 kg.
- Operating Temperature Range: 0°C to +55°C.
- Storage Temperature Range: -40°C to +70°C.
- Humidity: 5% to 95% (non-condensing).
- Installation Method: Inserted into HIMA rack slots.
HIMA F8621A
HIMA F8621X
HIMA F8627X Industrial Safety Communication Module
Procurement Guidance
- For safety systems: Verify model suffix 984862765 (SIL 3 certified) .
- For communication roles: Confirm EtherNet/IP or Profinet support via suffix (e.g., 3BSE006503R1) .
- Avoid misuse: Industrial automation applications require -40°C rating; commercial variants (0°C to +40°C) lack SIL 3 .
HIMA F8628X 984862865 Communication Module
Technical Specifications
- Communication Interfaces:
- Ethernet (10/100 Mbps) with RJ-45 connector for high-speed data transfer.
- PROFIBUS DP slave interface via a 9-pole SUB-D plug for integration with PROFIBUS networks.
- High-Speed Serial Redundancy (HSR) interface via RJ-12 plug for redundant communication.
- Processor: 32-bit Motorola CPU MPC860T with integrated RISC communication controller.
- Power Supply: 24 VDC (5 VDC/1 A operating voltage).
- Physical Dimensions: 3 HU (height units) x 4 SU (width units), compact design for easy installation.
- Diagnostic Display: 6 LEDs for real-time status monitoring and diagnostics.
- DIP Switches: 2 DIP switches for configuring module functions.
- Warranty: 1-year warranty with global shipping availability.
HIMA F8650E
-
Product Name: HIMA F8650E Safety System Central Processing Unit (CPU) Module
-
Product Introduction: The core processor for HIMA HIQuad (H51q) Safety Instrumented Systems. Executes user safety application program, performs 1oo2D / 2oo4D redundant processing, manages I/O communication, and logs Sequence of Events (SOE). Certified SIL 3 for ESD, HIPPS, F&G, burner management applications.
HIMA F8650X
-
Product Name: HIMA F8650X Safety Controller / Central Processing Unit Module (HIMax / HIQuad X Series)
-
Product Introduction: Successor to F8650E, the F8650X is the central CPU for HIMA HIMax and HIQuad X SIS platforms. Offers enhanced processing speed, larger memory, and native support for modern fieldbuses. Designed for ESD, F&G, HIPPS, turbine protection, and other SIL 3 / SIL 4 applications.
HIMA F8650X 984865065 Safety System Central Module
Technical Specifications
- Processor: High-performance processor (specific model may vary, e.g., ARM Cortex-A9 or similar, depending on configuration).
- Memory: Large-capacity memory, including DDR3 RAM (e.g., 512 MB) and NAND flash storage (e.g., 128 MB), for storing and processing extensive data.
- Communication Interfaces: Equipped with multiple communication ports, such as Ethernet, fieldbus, RS-232, and USB, facilitating seamless connectivity with other devices and systems.
- Power Supply: Operates on 24V DC power supply.
- Operating Temperature: Ranges from 0°C to +60°C.
- Storage Temperature: From -40°C to +85°C.
- Certifications: Meets stringent safety standards, including IEC 61508 and DIN 19250, with certifications such as TÜV AK7/SIL4.
HIMA F8652X 984865265 Central Control Module
Technical Specifications
- Processor: Based on Arm Cortex industrial-grade TDA4VM processor, ensuring high-speed processing for complex control tasks.
- Power Supply: 24V DC input with 0-10V DC output, providing a maximum current of 500mA.
- Physical Dimensions: 120mm x 80mm x 40mm, compact design for easy installation.
- Operating Temperature Range: -20°C to 60°C, suitable for harsh industrial environments.
- Communication Interfaces: Supports multiple protocols including Ethernet, serial port, Profibus, and CAN, enabling seamless data exchange with other devices.
- Safety Features: Equipped with overcurrent, overvoltage, and short-circuit protection functions to enhance system reliability.
- Programming Flexibility: Supports IEC 61131-3 standard PLC programming languages, allowing customization of safety logic.
HIMA H4135A
HIMA H6200A
Manufacturer: HIMA Paul Hildebrandt GmbH & Co KG (Germany)
Product Brief: The H6200A is the central CPU module of the HIMA H6000 or HIMatrix safety instrumented system (SIS), designed for high-integrity emergency shutdown (ESD), fire & gas (F&G), and burner management (BMS) applications. It executes certified safety logic with continuous self-diagnostics and fail-safe behavior.
HIMA K9202B
Product Introduction:
The HIMA K9202B is a safety-related terminal/interface module used in HIMA Safety Instrumented Systems (SIS). It provides a standardized field-wiring interface for HIMA F-series safety I/O modules via pre-fabricated system cables, enabling plug-and-play module replacement. In some configurations it also serves as a safety communication coupler supporting industrial Ethernet protocols for controller-to-controller or controller-to-host data exchange in SIL 3 environments.
