Yaskawa CVSR-404HCODENO71415-04051

Technical Specifications

• Power supply: 200/220 V AC, 50/60 Hz, 3-phase
• Control modes: Speed control, position control, torque control
• Feedback support: Incremental encoder, absolute encoder, resolver
• Analog input: ±10 V DC, 12-bit resolution
• Pulse input: Up to 500 kHz
• Power consumption: 1.2 kVA (maximum)

Functional Features

• High-precision speed regulation with ±0.01% speed stability
• Built-in auto-tuning PID controller
• Comprehensive protection functions: overcurrent, overvoltage, undervoltage, overheat, overload
• Panel-mounted design with front-facing operation indicators
• Adjustable acceleration and deceleration ramps

Application Scenarios

• Machine tool feed drives
• Conveyor and material handling systems
• Packaging and labeling machinery
• Textile production equipment
• Printing and paper processing machines

Performance Parameters

• Speed control range: 1:1000 (with 1024 PPR encoder)
• Speed response frequency: 30 Hz
• Positioning accuracy: ±1 encoder pulse
• Torque control accuracy: ±3% of rated torque
• Overload capacity: 150% for 60 seconds

Material Composition

• Housing: Cold-rolled steel sheet with electrostatic powder coating
• Circuit board: FR-4 flame-retardant epoxy glass substrate
• Power components: High-grade silicon power transistors
• Connectors: Nickel-plated brass terminal blocks

Structural Features

• Panel mount construction with standard cutout dimensions
• Integrated aluminum heat sink for natural convection cooling
• Removable terminal blocks for quick installation and maintenance
• Front-facing LED indicators for power, status and fault diagnosis

Working Principle The controller receives command signals from a host control system, compares them with real-time feedback signals from the motor encoder or resolver, and processes the error through a PID control algorithm. It then generates PWM (Pulse Width Modulation) signals to drive the power stage, adjusting the output voltage and current to achieve precise control of motor speed, position and torque.

Installation Requirements

• Mount vertically with at least 100 mm clearance on the top and bottom for ventilation
• Ambient operating temperature: 0°C to +45°C
• Storage temperature: -20°C to +60°C
• Relative humidity: 10% to 90% (non-condensing)
• Installation altitude: Up to 1000 m above sea level

Operation Notes

• Disconnect all power sources before performing wiring or maintenance
• Ensure proper protective grounding to avoid electromagnetic interference
• Do not operate the unit with the front cover removed
• Periodically inspect the heat sink and cooling vents for dust accumulation
• Do not exceed the rated motor current for continuous operation
