TRICONEX 4000206-520

• Processor and Memory Parameters
  • It is equipped with a 32-bit TriCore VME processor that delivers powerful computing capabilities to support the rapid execution of complex safety control logic.
  • It has 16 MB of RAM for real-time data processing and 2 MB of Flash ROM for storing system programs and configuration data, ensuring stable data storage and quick access.
• Communication and Backplane Parameters
  • It is configured with serial ports and Ethernet ports for data interaction with upper monitoring systems and external devices.
  • It uses the TriBus backplane with a communication rate of 25 Mbps, which guarantees efficient and stable data transmission between the module and matching I/O modules.
  • It supports connection with an RS-232 optical isolation interface, which enhances the module's anti-interference ability during communication.

• Input and Signal Parameters
  • The analog input version has 32 shared points, with a nominal input current of 4 - 20mA DC and an operating current range of 2 - 22mA DC. It has a 16-bit resolution and an accuracy of ±0.01% within the 1000 - 20000Hz frequency range.
  • The pulse input version has 8 high-frequency input points, a pulse count measurement resolution of 1 microsecond, and an input diagnostic fault range of 0.5% of the full scale. The input change sampling cycle is the longer one between one scan and 210 milliseconds.
  • The module has an input bandwidth of 16Hz, an absolute maximum field voltage of 33V DC, and an absolute maximum reverse field voltage of -0.6V DC.
• Power and Electrical Parameters
  • The nominal power supply voltage is 24V DC. The minimum isolation between functional and protective earth is 500V DC, and the minimum isolation between functional and functional earth is 800V DC.
  • The module has a source impedance of 180Ω, an input impedance of 250Ω when paired with a baseplate, and a 100Ω I-to-V resistor with a tolerance of ±0.01%.

• Electrical Parameters
  • It is equipped with 32 output channels, the nominal output voltage is 24 VDC, and the adaptive voltage range is 16 - 32 VDC, with a maximum withstand voltage of 36 VDC.
  • Each output channel has a maximum output current of 1.7 A, a surge current of 7 A that can last for 10 milliseconds, a minimum load current of 10 mA, and a maximum load leakage current of 4 mA.
  • The isolation voltage between channels reaches 1500 VDC to effectively prevent electrical interference between different channels, and the overall power consumption of the module is less than 13 watts.
• Physical Parameters
  • The module has dimensions of 160 x 160 x 125 mm and a weight of approximately 2.5 kg, which is suitable for installation in the slot of the Triconex system rack.
  • It adopts a corrosion-resistant metal shell, and is equipped with LED indicators for each output channel and overall status, which can directly display the working state of the module and each channel.

Technical Specifications:

• Type: Typically serves as an interface or communication module within the Tricon system.
• Communication Protocols: Supports industry-standard protocols to ensure compatibility with various control systems and devices.
• Power Supply: Operates within specified voltage ranges suitable for industrial environments.
• Environmental Endurance: Designed to withstand harsh conditions including wide temperature ranges, humidity, and exposure to dust.
• Certifications: Certified for use in Safety Instrumented Systems (SIS) up to Safety Integrity Level 3 (SIL 3), ensuring compliance with stringent safety standards.
