Triconex 2350

• Processor and Memory Parameters
  • It is equipped with an Intel Core i7 - 4790 or PowerPC 604e processor, with a main frequency of up to 1.3 GHz, which can efficiently support the operation of complex control algorithms and large - scale system data processing.
  • It supports a maximum of 16GB DDR3L RAM, and is configured with a 2GB SSD for storage, which can stably store a large number of control programs, configuration parameters and real-time operation data of the system.
• Power and Environmental Parameters
  • The input voltage is 24V DC, the output voltage is 5V DC, and the maximum power consumption is 22W, which meets the power supply standards of industrial control systems.
  • The operating temperature range is -40°C to +70°C, and the storage temperature range is -40°C to +85°C. It can adapt to the extreme temperature changes of most industrial sites.
  • It can work normally in an environment with a humidity of 5% to 95% non-condensing, has an anti - shock capacity of 30g (11ms) and an anti - vibration capacity of 5g (10 - 150Hz).

• Communication Port Parameters
  • It is equipped with three configurable RS - 232/485 serial ports and two Ethernet ports. Some versions can be configured with four serial ports, with a total data transmission rate of 460.8 kilobits per second for all serial ports.
  • The two Ethernet ports include 802.3 copper Ethernet ports and fiber - optic Ethernet ports in different models, with the Ethernet transmission speed reaching 100Mbps.
  • The first serial port can support Modbus or Trimble GPS interface, and the fourth serial port can be configured as Modbus or Tristation interface.
• Power and Electrical Parameters
  • The nominal input voltage is 24V DC, and the working voltage range is 19.2V DC to 30V DC, which can tolerate 5% AC ripple.
  • The maximum power interruption time allowed from the nominal voltage is 1 millisecond, the minimum repetition rate of power interruption is 1 second, and the maximum logic power consumption of the module is 8 watts.

• Electrical Parameters
  • It is equipped with 32 output channels, the nominal output voltage is 24 VDC, and the adaptive voltage range is 16 - 32 VDC, with a maximum withstand voltage of 36 VDC.
  • Each output channel has a maximum output current of 1.7 A, a surge current of 7 A that can last for 10 milliseconds, a minimum load current of 10 mA, and a maximum load leakage current of 4 mA.
  • The isolation voltage between channels reaches 1500 VDC to effectively prevent electrical interference between different channels, and the overall power consumption of the module is less than 13 watts.
• Physical Parameters
  • The module has dimensions of 160 x 160 x 125 mm and a weight of approximately 2.5 kg, which is suitable for installation in the slot of the Triconex system rack.
  • It adopts a corrosion-resistant metal shell, and is equipped with LED indicators for each output channel and overall status, which can directly display the working state of the module and each channel.

Technical Specifications:

• Type: Typically serves as an interface or communication module within the Tricon system.
• Communication Protocols: Supports industry-standard protocols to ensure compatibility with various control systems and devices.
• Power Supply: Operates within specified voltage ranges suitable for industrial environments.
• Environmental Endurance: Designed to withstand harsh conditions including wide temperature ranges, humidity, and exposure to dust.
• Certifications: Certified for use in Safety Instrumented Systems (SIS) up to Safety Integrity Level 3 (SIL 3), ensuring compliance with stringent safety standards.
