REOTRON 567LH-DP24

Series: 567 Series

Product Introduction:
The REOTRON 567LH-DP24 is a DIN rail-mount temperature transmitter with dual input capability (accepts RTD Pt100/Pt1000 or Thermocouple Type J/K/T/E/N/S/R/B). The “DP24” suffix indicates a 24 VDC powered, 4–20 mA output configuration with dual process input.

Category: Others

Description

Technical Specifications:

Parameter	Value
Product Type	DIN Rail Temperature Transmitter
Input Type	RTD Pt100 / Pt1000 (2/3/4-wire) OR Thermocouple (J, K, T, E, N, S, R, B)
Dual Input	2 independent inputs (Input 1 + Input 2)
Output Signal	4–20 mA DC (2-wire, per input)
Output Scaling	User-configurable: -50°C to +850°C (depending on sensor)
Supply Voltage	24 VDC (DP24 suffix)
Accuracy	±0.1% of Span (RTD) / ±0.5% of Span (TC)
Cold Junction Compensation	Automatic (for TC inputs)
Housing	Plastic, DIN rail 35 mm (EN 60715)
Ingress Protection	IP20
Operating Temperature	-20°C to +60°C
Dimensions	90 x 62 x 110 mm (W x H x D)
Weight	Approx. 120 g
Standards	CE, ATEX (optional)

Functional Features:

Dual-channel input — monitors 2 temperature points with independent 4–20 mA outputs
Auto-sensor detection — identifies Pt100 vs Pt1000 vs TC type automatically
Linearization — built-in for all standard RTD and TC curves
DIP switch / PC configuration — set range, damping, output direction (direct/reverse)
Fault detection — sensor open-circuit, short-circuit, out-of-range alarm

Applicable Industries:
HVAC, Food & Beverage, Pharmaceutical, Chemical, Power Generation, Plastics

Installation Requirements:

Mount on DIN rail EN 60715 (35 mm)
For RTD: use 3-wire or 4-wire connection to eliminate lead resistance error
For TC: use correct extension wire type (e.g., Type K extension for Type K TC)
Keep sensor cables away from power cables (min. 100 mm separation)

Usage Notes:

DP24 = 24 VDC power supply — do not apply 120 VAC or other voltages
Set output direction: Direct (4 mA = Low Temp, 20 mA = High Temp) or Reverse
Recalibrate annually per ISO 17025
