NSK ER‑FC‑2048D

Functional Features: Low‑noise ER‑grade mechanical construction; quadrature incremental signal output; zero‑position index pulse for homing; robust anti‑vibration internal assembly; differential output supports long‑distance noise‑resistant transmission.

Application Scenarios: Precision servo motors, machine‑tool rotary axes, semiconductor processing equipment, industrial robot joint feedback, high‑speed positioning rotary tables.

Performance Parameters: Phase difference tolerance ±45° electrical; output rise‑fall time less than 200 ns; vibration resistance 10‑2000 Hz; shock resistance 1000 m/s²; operating temperature ‑20 °C ~ +70 °C.

Material Composition: Aluminum alloy housing; optical glass code disc; phosphor‑bronze contact spring assembly; high‑strength engineering plastic internal support structure; gold‑plated connector pins.

Structural Characteristics: Hollow‑shaft mounting architecture; integrated coupling‑compatible shaft bore; metal shielding shell for electromagnetic interference suppression; standard industrial connector interface.

Working Principle: Infrared LED light source passes through the rotating optical code disc, and the photodiode array converts the light‑shadow pattern into electrical pulse signals; the signal processing circuit outputs differential quadrature A/B/Z incremental position feedback for the motion controller to calculate position and speed.

Installation Requirements: Allow specified shaft misalignment tolerance; avoid excessive axial or radial pressing force on the encoder shaft; secure connector locking; maintain sufficient cable bending radius; ground the encoder housing to the machine protective ground.

Usage Precautions: Never apply mechanical impact to the code‑disc assembly; prevent oil, coolant and conductive dust ingress; strictly use 5 V DC power supply; separate encoder signal cables from high‑power motor power cables; check phase‑sequence matching after installation before power‑on operation.
