NEC FC‑9801‑KB6

Technical Specifications: Working voltage 24 V DC; operating temperature ‑20 °C ~ +60 °C; weight 0.75 kg; dimension 150 mm × 100 mm × 50 mm; galvanic isolation for signal channels; multi‑channel D‑sub external connectors; support Modbus RTU protocol; rack‑mount installation mode.

Functional Features: Multi‑channel external signal interface expansion; signal galvanic isolation protection; front‑panel status LED indicators; plug‑and‑play with FC‑9801 series mainframe; support hot‑swap operation; over‑voltage and over‑current protection for each channel; anti‑interference circuit for industrial environment.

Application Scenarios: Industrial production‑line signal expansion, equipment external sensor interface expansion, automation equipment communication port expansion, factory floor field‑device connection, industrial control system peripheral signal adaptation.

Performance Parameters: Signal isolation voltage 1500 Vrms; maximum communication baud rate 115200 bps; channel over‑current protection threshold 500 mA; MTBF ≥100000 hours.

Material Composition: FR‑4 printed circuit board; metal shielding housing; D‑sub multi‑pin connectors; isolation optocoupler chips; TVS surge‑protection components; gold‑plated backplane contact pins.

Structural Characteristics: Rack‑mount plug‑in module structure; front panel equipped with multiple D‑sub external signal connectors and LED status indicators; rear side adopts high‑density gold‑plated backplane connector for connecting to main CPU backplane; metal housing provides electromagnetic shielding function.

Working Principle: Receive internal bus signals from main CPU through backplane connector; perform galvanic isolation and signal level conversion via optocoupler and signal conditioning circuit; transmit processed signals to external field equipment through front‑panel connectors; monitor channel status in real‑time and feed‑back fault signals to main controller.

Installation Requirements: Insert into designated expansion slot of FC‑9801 series rack; ensure backplane connector is fully engaged; connect external field‑wiring to front‑panel D‑sub connectors strictly according to pin definition; cabinet ventilation condition meets temperature requirement; protective ground connection must be completed.

Usage Notes: Power‑off operation during module disassembly; strictly follow pin assignment for external wiring; avoid short‑circuit of external signal lines; prevent mechanical damage to D‑sub connectors; ESD protection is required during maintenance; do not operate beyond rated temperature and voltage range.
