Motorola IPMC761

Product Name:​ VMEbus Single Board Computer (SBC) / Processor Module — IPMC761
Product Introduction:​ VMEbus-compatible embedded controller based on Motorola 68000-series (MC68020/MC68030) architecture; intended as a CPU/node controller in VME chassis for industrial automation, defense/aerospace, and telecommunications systems running RTOS such as VxWorks or pSOS.
Category:
Description
Technical Specifications:
  • Processor:​ MC68020 or MC68030, 20–33 MHz (varies by revision)
  • Memory:​ Onboard SRAM (typically 128 KB–512 KB), DRAM expandable; Flash/EPROM for boot firmware (up to 16 MB typical)
  • Bus Interface:​ VMEbus (IEEE 1014), A16/A24/A32 address modifier support, interrupt handler, DMA controller
  • I/O Interfaces:​ 1–2 × RS-232 serial ports (DB-9 or header), parallel port, optional Ethernet (10/100 Mbps on later revisions), SCSI (on some versions)
  • Timers:​ Dual programmable interval timers, watchdog timer
  • Operating System Support:​ VxWorks, pSOS+, proprietary embedded monitors; bootstrap from on-board ROM or network
  • Power Requirement:​ +5 VDC primary (typical consumption 2–5 W depending on memory/options)
  • Form Factor:​ Single-height VME-6U (160 mm × 100 mm PCB); depth per VME standard
  • Operating Temp:​ 0 °C to +55 °C (industrial grade; extended -40 °C to +85 °C on select versions)
  • MTBF:​ Typically > 100,000 hrs
    Structure & Working Principle:​ Plugs into VME backplane as slot-1 system controller or as a peripheral processor; arbitrates VME bus, executes application code from local memory, communicates with other VME modules via shared memory or mailbox interrupts.
    Applications:​ Legacy industrial control systems, semiconductor tool control, military/aerospace test rigs, power utility substation controllers utilizing VME architecture.
