LG LM201

Technical Specifications​

Diagonal 20.1 in, 511.13 mm. Resolution 1680 x 1050, WSXGA+, RGB vertical stripe. Aspect 16:10. Pixel pitch 0.258 x 0.258 mm, dot pitch 0.086 x 0.258 mm. Active area 433.44 x 270.9 mm. Outline 459.4 x 296.4 mm; depth varies by revision, around 17.7 mm to 24.2 mm. Logic voltage 12.0 V typical; LVDS logic consumption around 4.6 W to 5.3 W. Interface LVDS 2-channel 8-bit, 30-pin HRS KDF71G-30S-1H 1.0 mm on configured revisions. Backlight CCFL 6 lamps, edge top/bottom, 770/785/885 V, 3/7/7.5 mA, 40/60/80 kHz, startup 1300/1600 V, life around 45,000 h minimum. Brightness 250/300 cd/m² depending on revision. Contrast 500:1 to 800:1 depending on revision. Color 16.7 M 8-bit. Viewing angles 89/89/89/89 CR≥10. Response 7/9 ms Tr/Td. Surface anti-glare haze 25%, hard coating 3H. Operating temperature 0 °C to 50 °C; storage -20 °C to 60 °C.

Function Features​

Wide IPS/s-IPS viewing, 16:10 productivity resolution, LVDS compatibility with standard T-con boards, CCFL backlight for legacy industrial replacement, side M3 mounting holes, anti-glare industrial surface.

Structure Characteristics​

a-Si TFT glass, RGB stripe sub-pixels, source/gate driver ICs, LVDS timing controller, 12 V power circuit, CCFL edge-light guide with six lamps, aluminum/plastic bezel-compatible housing, 30-pin signal connector and separate CCFL inverter connectors.

Working Principle​

The T-con receives LVDS video, generates row/column timing and drives TFT pixels through source/gate drivers. Each pixel transmits backlight according to 8-bit gray data. The CCFL inverter supplies high-voltage AC to the lamps; the light guide distributes uniform illumination through the IPS liquid-crystal layer.

Installation Requirements​

Use 12 V regulated logic supply and a matched CCFL inverter with 6-lamp output. Connect 30-pin LVDS with correct channel/polarity; confirm 2-port 8-bit mapping. Mechanically fix using side M3 holes; avoid bending the TFT glass. Provide EMI shielding for LVDS and inverter wiring.

Usage Precautions​

CCFL inverter output is high voltage; service only with power off and capacitors discharged. Do not exceed 12 V logic or lamp voltage/current ratings. Operate within 0 °C to 50 °C; storage limits are not operating limits. Replace inverter/lamps together if brightness becomes uneven. Avoid pressure on the panel surface and contamination of the LVDS connector.
